• Model NO.：GD-9168
• Cooling Mode：Semiconductor
• Setting Range of Vacuum Pressure Residue：(0.133~13.2)Kpa
• Range of Vacuum Pressure Residue：(0.133~20)Kpa+-0.00133kpa
• Capacity of Buffer Tank：15L
• Warranty：1 Year
• Transport Package：Plywood
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100 PCS , Month

Basic Info.

Model NO. GD-9168 Cooling Mode Semiconductor Setting Range of Vacuum Pressure Residue (0.133~13.2)Kpa Range of Vacuum Pressure Residue (0.133~20)Kpa+-0.00133kpa Capacity of Buffer Tank 15L Warranty 1 Year Transport Package Plywood Origin Made in China HS Code 9031809090 Production Capacity 100 PCS / Month

Product Description

ASTM D1160 (ISO 6616) Vacuum Distillation Apparatus for the distillation of petroleum products



Introduction:

The Automatic Vacuum Distillation Apparatus is designed and made as per the national standard of People's Republic of China GB/T 9168-1997(2004)Standard Test Method for Distillation of Petroleum Products at Reduced Pressure. The Automatic Vacuum Distillation Apparatus is used to determine the range of boiling points for petroleum products that can be partially or completely vaporized at a maximum liquid temperature of 400ºC.


Features:

1. High-precision digital vacuum detecting system. It controls the vacuum pressure automatically and display it in real time. The vacuum pressure residue is (0.133~20)kPa±0.00133kPa.
2. It adopts advanced semiconductor refrigeration technology.
3. It is equipped with a self-developed high standard atmospheric pressure- reduced pressure automatic conversion software. The conversion precision is highly improved.
4. Automatic data saving. It can save 30 groups of test data. A needle printer is equipped. It can print the test result automatically.
5. The Automatic Vacuum Distillation Apparatusequips a double tempered-glass door. The test procedures are clear.
6. Independent heating furnace. The height is adjustable. Forced air cooling. The test efficiency is highly improved.



Specifications:

1. Power supply: AC220V 50Hz.
2.Total power consumption: ≤2000W
3. Receiving cylinder water circulation: The temperature control point is continuously adjustable.Ambient to 80ºC±2ºC. Automatic.
4. Cooling mode: Semiconductor
5. Setting range of vacuum pressure residue:(0.133~13.2)kPa
6. Measuring range of vacuum pressure residue:(0.133~20)kPa±0.00133kPa
7. Capacity of buffer tank:15L
9. Working environment: Ambient temp.:5~35ºC  RH:< 85%
10. Dimension: 930mm*620mm*1120mm
11. Net weight:  61kg.
