Rcr Ramsbottom Carbon Residue Apparatus for Testing The Carbon Residue of a Fuel

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Type：Universal Testing Machine
  • Display：Digital
  • Weight：0-100Kg
  • Power Source：AC220V
  • Test Method：Ramsbottom Method (ASTM D524)
  • Application：Lubricating Oils, Heavy Liquid Fuels

Base Info

  • Model NO.：GD-30011
  • Structure：Heating Furnace and Controller
  • The Max Temperature of Heating Furnace：520c
  • Heating Mode：Electric Furnace
  • Temp. Control Range：(0~520)C
  • Test Furnace：One Furnace with Four Holes
  • Ambient Temperature：Room Temperature (15~35)C
  • Warranty：1 Year
  • Transport Package：Plywood
  • Origin：Made in China
  • HS Code：9031809090
  • Production Capacity：100 Sets , Month

Description

Basic Info.

Model NO. GD-30011 Structure Heating Furnace and Controller The Max Temperature of Heating Furnace 520c Heating Mode Electric Furnace Temp. Control Range (0~520)C Test Furnace One Furnace with Four Holes Ambient Temperature Room Temperature (15~35)C Warranty 1 Year Transport Package Plywood Origin Made in China HS Code 9031809090 Production Capacity 100 Sets / Month

Product Description

RCR Ramsbottom Carbon Residue Apparatus for testing the carbon residue of a fuel

Rcr Ramsbottom Carbon Residue Apparatus for Testing The Carbon Residue of a Fuel


RCR Apparatus:

The Ramsbottom Carbon Residue Apparatus is designed and made as per industrial standard of People's Republic of China SH/T 0170 Test Method for Carbon Residue of Petroleum Products-electric furnace method.
The Ramsbottom Carbon Residue Apparatus is suitable to determine the carbon residue of lubricating oils, heavy liquid fuels and other petroleum products.



Features:

1. The Ramsbottom Carbon Residue Apparatus adopts desktop configuration. The heating furnace and controller are assembled to all-in-one machine. Small dimension and easy to use.
2. The max temperature of heating furnace can reach 520ºC. It adopts digital temperature controller. The temperature control accuracy can reach ±5ºC.
3. It can do four sample determinations concurrently. The test efficiency is high.


Specifications:

1. Power supply:   AC(220±10%)V, 50Hz
2. Heating power:   ≤1300W
3. Heating mode:   Electric furnace
4. Temp. Control range:   (0~520)ºC
5. Temp. Control accuracy:  ±5ºC
6. Test furnace:  One furnace with four holes
7. Ambient temperature:  Room temperature  (15~ 35)ºC; Relative humidity:  ≤85%
8. Dimension:  350mm*360mm*365mm
9. Net weight: 24kg.
