• Model NO.：GD-8017A
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-8017A Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Reid Automatic Vapour Pressure Tester for gasoline, solvents, light crude oils


Introduction:

This Automatic Vapour Pressure Tester is made and designed as per national standard of People's Republic of China GB/T 8017 Petroleum Products- Determination of vapor pressure- Reid method. It can also be used to do determination according to ASTM D323 Standard Test Method for Vapor Pressure of Petroleum Products (Reid Method). It is used to make determination for vapor pressure of gasoline, volatile crude oil and other volatile petroleum products. It cannot be used to determine the vapor pressure of LGP. It is fully-automatic vapor pressure tester by PC control and operation.


Key Features:

This Automatic Vapour Pressure Tester consists of two parts: "built-in industrial computer and color touch screen" and "instrument host". The desktop structure and the integrated machine form have reasonable design, compact structure, low failure rate and stable and reliable operation. The instrument can automatically complete the sample pressure and temperature detection during the test; automatic management and control of the test process; automatic sampling, analysis and calculation of test data; real-time display of test curve of test process; automatic display of test results, etc.

The Automatic Vapour Pressure Tester has high degree of automation, accurate test results, good repeatability and convenient operation.

It adopts advanced heating technology, while fundamentally achieving water and electricity separated, the separator used to cover the heating tube in the water bath is removed, so that the total height of the water bath is reduced, there is no dead angle in the bath, and the bottom is clearly seen. Water saving, it is also convenient for users to regularly clean the water bath.

The movement mode of the test bomb is changed from the traditional horizontal axial 350 degree rotation to the "saw plate" type movement, so that the sample is more fully stirred in the test bomb, more in line with the requirements of the standard, and the test results of saturated vapor pressure are more accurate.

Built-in heating protection function, when there is no water in the water bath or too little water, the system will automatically cut off the heater and stop the pump, which can avoid damage to the heater and pump.


Parameters:


1	Power supply	AC(220±10%)V, 50Hz
2	Maximum power consumption	1700W
3	Test bomb.	Can do 3 bomb tests at a time
4	Water bath temperature	37.8ºC
5	Temperature control accuracy	±0.1ºC
6	Heating power	1600W
7	Movement of bomb	Seesaw type
8	Pressure range	(0~200) kPa or (0~29) psi
9	Ambient temp.	(5~35)ºC
10	Relative humidity	≤85%
11	Dimension	600mm*500mm*512mm
