• Model NO.：5609
• Testing Angle：45°
• Loading：Adjustable, 500g, 250g
• Test Platform Moving Speed：5mm,Sec, Adjustable
• Stroke Distance：40mm
• Accessories：Standard Pencil 6b-6h, a Total of 13 Pieces
• Transport Package：Standard Export Case Packing
• Trademark：Minder
• Origin：China
• Production Capacity：60sets,Month

Basic Info.

Model NO. 5609 Testing Angle 45° Loading Adjustable, 500g, 250g Test Platform Moving Speed 5mm/Sec, Adjustable Stroke Distance 40mm Accessories Standard Pencil 6b-6h, a Total of 13 Pieces Transport Package Standard Export Case Packing Trademark Minder Origin China Production Capacity 60sets/Month

Product Description

Product description
Electric pencil hardness tester is specially used for spray hardness test of all kinds of finished products, such as: mobile phone shell, MP3/MP4 shell, notebook computer shell, etc. The machine is electric(semi-automatic) control, the machine moves through a stepper motor to achieve front and rear movement, low noise and stability. The test stroke can be adjusted according to the specific requirements.
Technical parameters

Product name	Touch screen electric pencil hardness tester
Model	5609
Testing angle	45°
Loading	Adjustable, 500g, 250g
Test platform moving speed	5mm/sec, adjustable
Stroke distance	40mm
Platform	About 12*17cm, can fix samples
Power supply	220V/50Hz
Accessories	Standard pencil 6B-6H, a total of 13 pieces

If you need more further details about our machines,  please feel free to contact us .
