ASTM D665 Lubricating Oils Rust Preventing Characteristic Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Power Source：AC220V
  • Product Name：ASTM D665 Lubricating Oils Rust Preventing Charact
  • Standard：ASTM D665
  • Test Sample：Gasoline, Volatile Crude Oil and Other Volatile
  • Test Bomb：Can Do 4 Bomb Tests at a Time
  • Temperature Control Range of Bath：Ambient to 100

Base Info

  • Model NO.：GD-11143
  • Temperature Control Accuracy：0.1
  • Dimension：580*320*600mm
  • Temperature Display：Digital
  • Timing Function：Yes
  • Transport Package：Wooden Case for ASTM D665 Rust Preventing Characte
  • Specification：580*320*600MM
  • Trademark：Gold
  • Origin：China
  • Production Capacity：100 Sets,Month

Description

Power supply

AC(220±10%)V, 50Hz

Temperature range

0ºC~100ºC

Temperature control accuracy

±1ºC

Temperature sensor

RTD, Pt100

Temperature display

Digital display

Timing range

1min~24hour, can be set at will

Time display

Digital display

Temperature control heating power

600W

Auxiliary heating power

1000W

Rotate speed of stirring motor

1400RPM

Sample stir rate

(1000±50)r/min

Sample testing positions

Four positions

Ambient temperature

(Room temp.~35)ºC

Relative humidity

≤85%

Maximum power consumption

1800W

Dimension

580mm×320mm×600mm




GD-11143 Lubricating Oils Rust-Preventing Characteristics Tester Accessories and Documents List

No.NameUnitQtyMemo1

GD-11143 Lubricating Oils Rust-Preventing

Characteristics Tester

Set1 2Beaker holderPiece4 3Sample stirring rodPiece4 4Sample rod handlePiece4 5Sample rodPiece4 6Sample rodPiece4 7BeakerPiece6 8Thermometer 0~100 ºC,scale division 0.5 ºCPiece1 9Fuse 15A  (5×20)  Piece2 10Temperature sensor Piece1 11Power line (250V10A) Piece1 12Stopping ring for thermometer (1#)Piece4 13Bath coverPiece4 14Operation manual Piece1 15Temperature control device uasge manualPiece1 16Timer usage manualPiece1 17Quality CertificatePiece1 18Repair GuaranteePiece1



GD-11143 Lubricating Oils Rust-Preventing Characteristics Tester's Reagent and Auxiliary Equipments

No.

Name

Specification

Quantity

Memo

1

Isooctane

Analytical pure 500ml

3 bottles



2

Petroleum ether (90-120ºC)

Analytical pure 500ml

3 bottles



3

Acetone chromic acid lotion

500ml

1 bottle



4

Distilled water

3 grade

1 litre



5

Silicon carbide

150/240 granularity

10 piece

Alternative

6

Aluminium oxide abrasive cloth



10 piece



Notes:
1,The reagent and equipments for installing the instrument are supplied by end-users themselves.
2,The usage,management and saving of poisonous and harmful reagent,pls operate according to the relative principle.
3,PLS read the operation manual and industry standard before using the instrument.


Company  Information:

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.

Our company mainly design and manufacture the petroleum testing instrument .

After several years' development, our products receive high intelligent and wide coverage. And our company has become one of the leading manufacturer of petroleum testing instrument.
