• Model NO.：GD-2018
• Transport Package：Wooden Case or Plywood
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-2018 Transport Package Wooden Case or Plywood Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

ASTM D6560 Wax / Gum / Asphaltene Content in Crude Oil Tester


Introduction:

ASTM D6560 Asphaltenes testing for crude oils and petroleum refined products.
The instrument is suitable for the determination of wax, gum and asphaltene content in crude oil.
The method is to dissolve a sample with n-heptane, then filter out insoluble matter. After the n-heptane reflux is used to remove the oil wax and the gum in the insoluble matter, the asphaltene is dissolved by refluxing with toluene to remove the solvent and the amount of the asphaltenes obtained. The other sample was separated by an alumina column and the toluene-acetone mixture was used as a dewaxing solvent. The wax content was determined by freezing crystallization. The gel content is obtained by the reduction method.


Features:

1. Fully enclosed compressor refrigeration, large cooling capacity and low noise.
2. Stainless steel heating bath, stainless steel heating tube, circulation pump cycle.
3. Microcomputer temperature control, PID temperature control, PT100 temperature sensor, high precision.
4. A standard adsorption unit with a thermal bath circulation system.
5. Equipped with a wax separation tube, a filter funnel and a dewaxing device.


Specifications:


1	Refrigeration method	Compressor refrigeration
2	Refrigeration range	Normal temperature ~-35 °C
3	Heating method	Electric heating tube heating
4	Temperature control mode	Digital display PID temperature controller
5	Working power	AC220V, 50Hz
6	Stirring mode	Motor stirring
7	Applicable standards	SY/T7550 , SY/T0537, ASTM D6560
8	Heating temperature	Normal temperature ~ 45ºC
