• Model NO.：GD-0703-1
• The Number of Rolling：Software Can Be Set, The Default Is P1: 4 Times; P
• Test Mold Specifications：300*300mm
• Machine Weight：350kg
• Working Air Source：Pressure 0.7MPa, Exhaust Volume 40L , Min
• Working Power：AC380V, 50Hz, 3.0kw (Three-Phase Four-Wire System
• Transport Package：Wooden Case for Aphalt Pneumatic Wheel-Track Moldi
• Specification：1200*700*2000mm
• Trademark：GOLD
• Origin：China
• HS Code：9031809090
• Production Capacity：100 Sets, Month

Basic Info.

Model NO. GD-0703-1 The Number of Rolling Software Can Be Set, The Default Is P1: 4 Times; P Test Mold Specifications 300*300mm Machine Weight 350kg Working Air Source Pressure 0.7MPa, Exhaust Volume 40L / Min Working Power AC380V, 50Hz, 3.0kw (Three-Phase Four-Wire System Transport Package Wooden Case for Aphalt Pneumatic Wheel-Track Moldi Specification 1200*700*2000mm Trademark GOLD Origin China HS Code 9031809090 Production Capacity 100 Sets/ Month

Product Description

Aphalt Pneumatic Wheel-Track Molding Machine


Our Pneumatic wheel-track molding machine is suitable to make samples for wheel track test. Usually it is used with wheel track tester.
It is an automatic instrument integrating mechanical, computer, electrical, and pneumatic control. Compared with similar products, it has the characteristics of small size, high degree of automation, strong functions, and convenient operation. It is an ideal instrument for asphalt mixture compaction molding .



I. Introduction:
Pneumatic wheel-track molding machine is mainly used for molding test pieces before wheel track test. The test piece can be used for testing the physical and mechanical properties of asphalt mixtures such as the high temperature resistance to rutting of asphalt mixtures, and the high temperature stability of asphalt mixture ratio designs.



II. Main technical characteristics:
1. Using color touch screen, the operation of the instrument, data display, and parameter input can be completed on the touch screen.
2. The display screen shows the parameters such as wheel temperature, wheel pressure, and number of rolling times in real time.
3. The Pneumatic wheel-track molding machine is designed with a self-diagnostic function, which can automatically judge various faults and automatically display fault codes.
4. Adopting advanced air pressure control technology, the pressure of wheel can be arbitrarily set and adjusted within the range of (0 ~ 20) kN.
5. The height of the test mold can be set and adjusted arbitrarily within the range of (30 ~ 100) mm.
6. The clamping mechanism for installing the test mold is advanced, safe and reliable, and easy to use.
7. The PWM modulation method is adopted. The temperature of wheel can be set arbitrarily, with high accuracy and good stability. The temperature is displayed in real time.
8. Designed with safety protection door to ensure the safety of the operator.
9. With pressure calibration function, the user can calibrate the pressure of the wheel on the instrument.



III.the main technical parameters and indicators:

1	Wheel radius	500 mm, width is 300 mm
2	Load control range of roller compaction line	(200 ~ 700) N /cm (It can be adjusted arbitrarily. It is adjusted to 300 N / cm before delivery).
3	Load control accuracy of roller compaction line	± 3 N / cm
4	Control range of roller temperature	(room temperature ~ 200) ºC
5	Precision of roller temperature control	± 5 ºC
6	Rolling speed	6 times / min ± 0.5 times / min
7	the number of rolling	software can be set, the default is P1: 4 times; P2: 12 times
8	Test mold specifications	300 mm × 300 mm × (30 ~ 100) mm
9	Dimensions	1200mm × 700mm × 2000mm (length × width × height)
10	Machine weight	350kg
11	Working air source	pressure 0.7Mpa, exhaust volume 40L / min
12	Working power	AC380V, 50Hz, 3.0kW (three-phase four-wire system, yellow and green wires are zero wires)

IV.Related Products

GD-0719: Automatic wheel track tester
GD-0719A: Automatic wheel track tester(One wheel)
GD-0719B: Automatic wheel track tester(Two wheels)
GD-0719C: Automatic wheel track tester(Three wheels of scientific research)
