Laboratory Rotary Digester
Hangzhou Pnshar Technology Co., Ltd.- Type:Laboratory Rotary Digester
- Weight:100-500Kg
- Power Source:AC220V
- Pot Body:Stainless Steel
- Transport Package:Seaworthy or Airworthy Package
- Specification:ISO etc.
Base Info
- Model NO.:PN-PL1
- Trademark:PNSHAR
- Origin:Hangzhou, Zhejiang
- HS Code:90248000
- Production Capacity:300sets,Year
Description
Basic Info.
Model NO. PN-PL1 Trademark PNSHAR Origin Hangzhou, Zhejiang HS Code 90248000 Production Capacity 300sets/YearProduct Description
Laboratory Rotary Digester
1.Introduction:
This laboratory digester (electric cooking type ) is laboratory equipment used in pulp & paper making R&D. It is used for pulp & paper technology and material research & development and its production simulation.
The material and lotions in pot are mixed well by the circle movement of the pot, at the reset temperature and pressure, to cook the material. It is used for cooking all material of fibers.
2.Advantage:
1. Cylinder is made of stainless steel,
2. Electric cooking type.
3. Used in pulp & paper making R&D.
NO. | ITEM | SPECIFICATION |
1 | Pot capacity: | 15L |
2 | Working pressure: | ≤0.8Mpa |
3 | Working temperature: | ≤170°C |
4 | Pot rotation speed: | about 1rmp |
5 | Gear motor: | 0.25Kw, 380V/50Hz |
6 | Heating power: | 4.5Kw |
7 | Dimension: | 920*450*1230mm |
8 | Weight: | 250kg |
