20kn Plastic Tensile Tester Price (WDW-20)
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service：24 Hours Technical Supply
- Warranty：12 Months
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Universal Testing Machine
- Maxcapacity：50kn
Base Info
- Model NO.：WDW-20
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Computer
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：Without
- Delivery Time：3 Days After Get Tt Payment
- Standard：ASTM, GB, ISO, DIN
- Max Load：10,20kn
- Load Resolution：1,300000
- Max Tensile Space：800mm
- Cover：All Aluminum Alloy
- Grip：Wedge Grip
- Certificate：CE ISO
- Load Accuracy：1 Class
- Transport Package：Standard Export Packing
- Specification：700*450*1775mm
- Trademark：HST
- Origin：China
- HS Code：9024101000
- Production Capacity：800 Sets Per Month
Description
Four-column floor or desk model,
(upper is compression and lower is tensile)Cover All aluminum alloy Control method Computer control Load accuracy Class 1 Class 0.5 Class 1 Class 0.5 Load range 2%~100%F·S 0.2%~100%F·S 2%~100%F·S 0.2%~100%F·S Load resolution 1/300000 Rang of deformation 4%-100%FS Resolution of deformation 0.04um Accuracy of displacement Within±0.5%of indicating load Resolution of displacement 0.01mm Test speed(mm/min) 0.05-1000 stepless arbitrary setting Tensile space(mm) 800(can be customized) Compression space(mm) 800(can be customized) Test width(mm) 400(can be customized)
(upper is compression and lower is tensile)
