Ultrasonic Flaw Detector for Power Tower
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
- Weight：1.8 kg
Base Info
- Model NO.：GDUD-PTM
- Power Source：Lithium polymer battery
- Transmitting voltage：600V
- Sampling frequency：100MHz(Max.)
- Pulse repetition frequency：60Hz
- Dimension：210mm*165mm*50mm
- Relative humidit：20-90%RH
- Impedance matching：50Ω,500Ω
- Resolution：≥36dB(5N14)
- Transport Package：Standard Export Wooden Box
- Specification：210*168*50mm
- Trademark：HV Hipot
- Origin：Wuhan, China
- HS Code：9030899090
- Production Capacity：2000 PCS,Year
Description
Measurement mode
Flaw detection function
| Channel | 20groups |
| Storage | 500 echo signals |
| Display | Full freeze/reference freeze |
| Envelope curve | Peak envelope record display |
| Real time clock | Date/time tracking, standard clock timing |
| Interface | USB port, supporting computer communication and management |
Display
| Display | High-bright, true color TFT display, 5.7 inches |
| Frequency | NTSC(60Hz) |
Structure and use environment
| Battery | Lithium polymer battery, working time ≥ 10 hours |
| Dimension and weight | 210mmx165mmx50mm,1.8kg(with battery) |
| Environment temperature | -5ºC--60ºC |
| Relative humidity | 20-90%RH |
