Ista Paper Board Test Machine Carton Clamping Testing Equipment
Dongguan Haida Equipment Co., Ltd.- Type:Paperboard Testing Machine
- Maxcapacity:<1000KN
- Accuracy Grade:0.5
- Load Way:Electronic Load
- Loading Method:Dynamic Load
- Display:Digital
Base Info
- Model NO.:HD-A535
- Control:Computer Control
- Weight:500-1000Kg
- Power Source:AC220V
- Product Name:Carton Clamping Tester
- Max. Force:400~3000lb
- Load Cell:4 Load Cell for Highest Accuracy
- Control System:Touch Screen Controller, Windows 7, RS-232 Interfa
- Load Cell Resolution:1,250, 000
- Load Precision:Within ±0.25%
- Parallelism of Platens:Parallel Within±2.5mm
- Software:TM 2101
- Data Display:Load, Displacement, Speed, Loading Rate and Elapse
- Function:The Clamp Can Be up and Down
- Transport Package:Strong Wooden Case
- Specification:ASTM D642, ASTM D6055, ISTA 6Amazon
- Trademark:HAIDA
- Origin:Dongguan, China
- Production Capacity:150 Sets,Month
Description
Basic Info.
Model NO. HD-A535 Control Computer Control Weight 500-1000Kg Power Source AC220V Product Name Carton Clamping Tester Max. Force 400~3000lb Load Cell 4 Load Cell for Highest Accuracy Control System Touch Screen Controller, Windows 7, RS-232 Interfa Load Cell Resolution 1/250, 000 Load Precision Within ±0.25% Parallelism of Platens Parallel Within±2.5mm Software TM 2101 Data Display Load, Displacement, Speed, Loading Rate and Elapse Function The Clamp Can Be up and Down Transport Package Strong Wooden Case Specification ASTM D642, ASTM D6055, ISTA 6Amazon Trademark HAIDA Origin Dongguan, China Production Capacity 150 Sets/MonthProduct Description
ISTA Paper Board Test Machine Carton Clamping Testing EquipmentProduct Description:The ISTA Paper Board Test Machine Carton Clamping Testing Equipment is mainly used to simulate the influence of the clamping force on the package through the splint operation,during the clip car loading and unloading the goods
The clamp plate of equipment can prefer the operation of clamping,opening,rising,falling and ect.Also it can achieve a cycle action.It equips with the load sensor and digital monitor,as to display the clamping force.
STANDARD FEATURES:
Item | Description |
Max. Force | 400~3000Lb |
Maximum specimen weight | 600kg (can be customized) |
Load cell | 4 load cell for highest accuracy |
Control system | Touch screen controller, Windows 7, RS-232 interface |
Motor | Panasonic servo motor w/DC variable speed drive system, high-precision mechanical ball screw rod |
Force reading | kgf, Ibf, N, KN, T etc |
Load cell Resolution | 1/250,000 |
Load Precision | within ±0.25% |
Parallelism of Platens | Parallel within±2.5mm |
Clamping plate size | Height 48inchX depth 48inch |
Clamping plate adjustable height | 0~1000mm |
Clamping plate adjustable width | 200~2000mm |
Base plate dimension | 2200X 2100mm |
Test speed | 0.25-2.5mm/sec (according ISTA 6- SAMS CLUB) |
Software | TM 2101 |
Data display | Load, displacement, speed, loading rate and elapsed time |
Function | The clamp can be up and down |
Clamping plate requirement | Make the two clamping boards flat and non-deform under work condition (2000 Pounds) and make clamping boards' parallel and clamping board and land vertical. Clamping board is thicker than 25mm. |
Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
The Introduction Of Haida:
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.

Our Team:

Our Services:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
1. Pre-service
--24 Hours online service for your consult.
--Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
4. Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
5. Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc

Customer Feedback:

FAQ:
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 12 years focusing on test equipment field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 12 months by HAIDA,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each equiopment must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer's company when you need. products are widely recognized and trusted by users.
A :Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
