GDKC-15A High Voltage Loop Resistance Circuit Breaker Analyzer

HV Hipot Electric Co., Ltd.
  • After-sales Service：yes
  • Function：check
  • Display：Digital
  • Usage：Electric Component Tester
  • Type：Electric Inductance Measuring Tester
  • Environment：Room Temperature

Base Info

  • Model NO.：GDKC-15A
  • Warranty：1 year
  • Power Source：DC 100V-300V
  • Weight：〉10Kg
  • Installation：Direct Connected
  • Customized：Non-Customized
  • Current display：Maximum current 30A, resolution: 0.01A
  • Instrument power supply：AC,DC 220V±10%; 50Hz±2%
  • External trigger voltage：AC,DC10-300V, current≤120A
  • Operating Environment：-20ºC~+50ºC
  • Relative humidity：≤90%
  • Transport Package：Standard Export Wooden Box
  • Specification：360*260*170mm
  • Trademark：HV Hipot
  • Origin：Wuhan, China
  • HS Code：9031809090
  • Production Capacity：2000sets,Year

Description





Isolated switch measurement rangeVoltage output: DC10~260V (adjustable);Power output time: 0.01-20 seconds (can be set);The maximum acquisition time of the fracture signal is 200 seconds;Measurable fracture open, close time, three phases different period, bounce time and timeMeasurable fracture open, close time, three phases different period, bounce time and timeHost volume360×260×170mmOperating Environment-20ºC~+50ºCRelative humidity≤90%
