ASTM D2063 ASTM D3198 Automatic Cap Torque Tester for Bottle Caps
Pubtester Instruments Co., Ltd.- After-sales Service：on Line
- Warranty：12 Months
- Test Method：Full Automatic
- Specimen Clamping and Turning Way：Pneumatic
- Load Cell Capacity：5n.M
- Resolution：0.001n.M
Base Info
- Model NO.：DTT-02
- Bottle Height：20 mm~400 mm
- Statistical Analysis Allowance：0 ~ 50000
- Body Clamp Range：Dia5 mm~170 mm
- Cap Clamp Range：Dia 10 mm ~80 mm
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：30 Sets,Quarter
Description
Extended ApplicationApplication & Removal Torque of Screw Nut Open and lock force test of the screws Vacuum Flask and Vacuum Cup Open and lock force test of the caps of vacuum flasks and vacuum cups
Technical SpecificationsLoad Cell Capacity5 N·m(Standard) 20N·m, 40N·m (Optional) Accuracy 0.5% FS Resolution 0.001N·m Body Clamp Range Φ5 mm~Φ170 mm Cap Clamp Range Φ10 mm~Φ80 mm Bottle Height 20 mm~400 mm Maximum Removal/Application Torque 2 Nm (customization) Specimen Clamping and Turning Way Pneumatic Gas Supply Air (Not in supply scope) Gas Supply Pressure 0.7 Mpa (101.5psi) Statistical Analysis Allowance 0 ~ 50000 Instrument Dimension 570 mm (L) × 375mm (W) × 1200mm (H) Power Supply AC 220V 50Hz /120V 60Hz Net Weight 38 kg
Standards
ASTM D2063, ASTM D3198, ASTM D3474, GB/T 17876, BB/T 0025, BB/T 0034
Configuration
Standard Configuration:Instrument, Micro-printer, Auto Testing System
Optional Parts: Air Compressor
Note: 1.The gas supply port of the instrument is Φ4 mm PU Tubing;
2. Customers will need to prepare for gas supply.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
