• Model NO.：KMHW-4
• Quality：Assurance
• Volume：9m³
• Appearance：Good-Looking
• Accessories：From World Famous Company
• Company Philosophy：Integrity, Innovation, Service, Win-Win
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：standard and customized
• Trademark：KOMEG
• Origin：Dongguan China
• HS Code：90321000
• Production Capacity：800PCS,a Year

ModelKMHW-21Volume(m³)43.3 CBMInterior DimensionsW4800 x H2100 x D4300mmExterior DimensionsW5950 x H2350 x D4500mmSafety Devices(standard)No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protectionStandard accessoriesSight window*1, cable port ( portΦ50mm ) *1, chamber lamp*1, status indicatorControl System Balanced Temperature & Humidity Control SystemRefrigeration systemWater CooledSemi-hermetic compressor, single stage or cascade refrigeration system,CFC free refrigerant ( HFC-507 and HFC-23 )ControllerPanel7-inch LCD Touch panel, Chinese or English display selectableOperation modelProgram or fix point runningMemory capacity120 programs,1200steps, all repeat 999 cycles,part repeat 99 cyclesAccuracyTemp.:0.1% of F.S ± 1 digit  Humidity:0.1% of F.S ± 1 digitInputTemp.: pt-100, Humidity: pt-100 or ~5V DCVComm.port RS-232 or RS-485 ( Softawre is option)Temp. rangeMaximum: 80 ºC,120 ºC;
Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºCHumidity Range10%, 20%, 30% ~ 95%Temp. constancy±0.5 ºCHumidity constancy±2.5%R.HTemp. uniformity±2.0 ºCHumidity uniformity±5.0%R.HAmbient Temp.+5 ºC~+35 ºCWiring methodAC 380 ± 10% 50Hz ,3 phase 4 wires + Ground WiresHeat up time +20 ºC~+80 ºC, Within 60 minPull down time +20 ºC ~ -55 º,  -40 ºC, -20 ºC, -10 ºC, Within 120 or 90 or 60  minInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel ( SUS304)Insulation materialRigid polyurethane foamDoor size (mm)Single wing: W800 x H1800;  Double wing: W1600 x H1800;Note:1. We reserve the right to change specifications without prior notice   2.Customized sizes and configurations available
