• Model NO.：SXDVDF
• Loading Method：Static Load
• Display：LCD
• Control：Manual,Motorized,Auto
• Power Source：380V or at Option
• Frequency：150Hz; 100Hz
• Capacity：30kVA, 50kVA or at Option
• Phase：3 Phase
• Rated Speed：1480r,Min
• Transport Package：Plywood Case
• Specification：IEC ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030891000
• Production Capacity：100 Units

Basic Info.

Model NO. SXDVDF Loading Method Static Load Display LCD Control Manual/Motorized/Auto Power Source 380V or at Option Frequency 150Hz; 100Hz Capacity 30kVA, 50kVA or at Option Phase 3 Phase Rated Speed 1480r/Min Transport Package Plywood Case Specification IEC ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030891000 Production Capacity 100 Units

Product Description

SXDVDF  DVDF Test System

General Information:
The DVDF test system is specially designed and manufactured for the power transformer production and maintenance department to do the frequency doubling induction withstand voltage test power supply. It can only be used as the frequency doubling voltage withstand power supply, cannot be used as the general civil power supply, and cannot run for a long time, the maximum allowable continuous operating time is no more than 4 hours.The output frequency of the equipment is 150Hz and the maximum load transformer capacity is 2500kVA.Intermediate transformers are required when the voltage of the low-voltage side of the transformer exceeds 400V.


Main Parameters:

• Rated Capacity:30kVA (at customized)
• Rated Load (Transformer) Capacity:2500kVA
• Rated Input Voltage: Three-phase four-wire 380V/63A/50Hz
• Rated Output Voltage:Three phase 800V/21.7A/150Hz
• Exciting Voltage:Three phase 220V/20A/50Hz
• Rated speed: 1480r/min
• Power factor:0.8
• Output voltage waveform distortion rate:≤2%

Please send contact sansion for more details.
