60ton 600kn Electronic Tensile Strength Testing Equipment
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service：24 Hours Technical Supply
- Warranty：12 Months
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Universal Testing Machine
- Maxcapacity：600kn
Base Info
- Model NO.：WDW-600
- Accuracy Grade：1 or 0.5
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Computer Display
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：No
- Certification：CE ISO
- Transport Package：Plywood Exporting Package
- Specification：350kg
- Trademark：HST
- Origin：Jinan, Shandong, China
- HS Code：9024101000
- Production Capacity：1000 Sets,Month
Description
Four-column floor model, (upper is compression and lower is tensile)Control method Computer control Load accuracy 1 class/0.5 class Load range 2%~100%F·S/0.4%-100% FS Resolution 1/300000 Measuring range of deformation 0.2%-100%FS Accuracy Indication of deformation ≤±0.5% Disp. indicating relative error ≤±1% Displacement Resolution 0.04um Adjusting range of displacement rate 0.05-200mm/min(can be customized) Tensile space 700mm(can be customized) Compression space 650mm(can be customized) Test width 650mm(can be customized) Power supply AC220/380V±10%,50Hz(can be customized) Load Cell Configuration One(max load), more load cells can be added according to customer requirement Extend configuration Large deformation extensometer, high or low
temperature teste chamber, high temperature oven Grips Hydraulic automatic Dimension 1360*1000*2830mm Weight 3050kg
4. Main Unit Feature:
4.1 Adopt floor structure,High Stiffness, lower for tensile, upper for compression,upper for tensile, lower for compression, double space. The beam is step less lifting.
4.2 Adopting ball screw drive, realize no clearance transmission,make sure the precision control of the test force and deformation speed.
4.3 The shiel plate with limit mechanism used to control the beam moving range, in order to avoid sensor damaged due to the moving distance is too large.
4.4 The table, moving beams is made of high quality precision machining steel plate , not only reduce the vibration generated by specimen fracture, but also improve the stiffness.
4.5 Three columns of mandatory orientation, make the main unit rigidity much improved, to further ensure the repeatability of measurement.
4.6 Adopt bolt type grip installation, make the grip replace easier.
4.7 Adopt AC servo driver and AC servo motor, with stable performance,more reliable. Have over-current, over-voltage, over speed, overload protection device.
