• Model NO.：SXI-17
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Measuring Range：0~1999m Ohm
• Supply Current：About 20mA
•  Power Supply：9V Battery
• Resolution：1mΩ
• Measuring Voltage：About 5000V DC
• Transport Package：Carton or Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9031809090
• Production Capacity：100 Units

Basic Info.

Model NO. SXI-17 Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Under Measuring Range 0~1999m Ohm Supply Current About 20mA  Power Supply 9V Battery Resolution 1mΩ Measuring Voltage About 5000V DC Transport Package Carton or Plywood Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9031809090 Production Capacity 100 Units

Product Description

General Information:
SXI-17 De-Energized Insulator Tester is applied to Tester tests energized or de-energized insulators for non-visible internal failures at any AC line voltage. These non-visible failures are known causes of Radio Frequency/ Television Interference (RF/TVI), blinking lights, recloser operations and blown fuses. They are also a threat to line crew safety when performing energized maintenance. To detect non-visible insulator failures before they cause operations difficulties or safety threats to line crews. SXI-17 also can be used as insulation resistance meter.


Features:


√  Small size, light weight, about 1.36kG.

√  Battery supply, long continuous duty, easy to operate.

√  Energized or de-energized insulators are all detectable.

√  Build-in gigohm meter to limit current when 10kV DC is pressed on insulator.

√  Sound alarm on failure insulator.

√  LED screen.

√  Insulated rod (tube)'s length is customizable.

√  Portable carrycase.


Specifications:

√  Measuring voltage: about 5000V DC

√  Measuring range: 0~1999MΩ

√  Resolution: 1MΩ

√  Intrinsic error: ±5%

√  Power supply: 9V battery

√  Supply current: about 20mA

√  Environmental temperature: 0ºC~40ºC

√  Environmental humidity: ≤85%RH

√  Weight: about 1.36kG


More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
