• Model NO.：GDYZ-30D
• Power Frequency：50+,-1Hz
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030332000
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GDYZ-30D Power Frequency 50+/-1Hz Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 5000PCS/Year

Product Description

GDYZ-30D zinc oxide arrester tester is specifically designed to test the electric valve inner defects of zinc oxide lightning arrester for 10KV and below power system.

This device combined DC high voltage power supply with measure&control system, which size is smaller and weight is more lighter. It is an essential equipment for power system and Zinc Oxide lightning arrester manufacturer.


Features

Power supply: AC220V AC, or built-in rechargeable battery.
Easy to use: Visual measurement data display.
Measuring accuracy: All-digital processing, built-in sophisticated mathematical models, high accuracy, good repeatability of test results.
Light weight, easy to carry.


Technical parameters


Measuring range	Voltage: 0-30kV Current: 0-1000mA
Resolution	Voltage: 0.1 kV; Current: 0.5 micro-AMP.
Built-in power charge time	2-3 hours
Built-in power usage time	>=4 hours
Ambient temperature	-10~ 50degree
Relative humidity	25degree, <=85%
Altitude	<1000m.
Supply voltage	220V+/-10%
Power frequency	50+/-1Hz
