Primary Current Injection Test Set (GDSL-82-2000)
HV Hipot Electric Co., Ltd.- Model number：GDSL-82-2000
- Output current：0-2000A AC.
- Output voltage：6V
- Capacity：12kVA
- Input voltage：AC220V, Single phase, 50Hz
- Input current：54.5A
Base Info
- Model NO.：GDSL-82-2000
- Delivery time：10-15 days
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030899090
Description
Basic Info.
Model NO. GDSL-82-2000 Delivery time 10-15 days Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090Product Description
General information
GDSL-82-2000 series Manual Primary Injection Test Set, is the ideal equipment for testing high-current device in the power and electric industry, which is used in power plants, power distribution stations, electrical manufacturing and research institutes, with the features of small size, light weight, easy use and maintenance.
Features
1. Manually control, digital display.
2. Movable structure, current output is adjustable.
3. Customized current output as requirements.
4. Board ammeter, clamp ammeter, CT verification
5. Suitable for all kinds of circuit breaker, switchgear, current relay.
| Output current | 0-2000A AC |
| Output Voltage | 6V |
| Capacity | 12KVA |
| Input voltage | AC220V, Single phase, 50Hz |
| Input current | 54.5A |
| Operating time | 1min ON, 5mins OFF |
| Timer range | 0.001-99999ms |
| Ambient temperature | -20 ºC to 50 ºC |
| Current accuracy | ≤ 1.0% (F.S) |
