5kVA 5kV AC Hipot Test Set
HV Hipot Electric Co., Ltd.- Type：Withstand Voltage Test Set
- Maxcapacity：0-300kv
- Accuracy Grade：1.5%
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：GDYD-0505D
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Input：AC220V ± 10%
- Frequency：50Hz ± 1
- Output voltage：0-5kV, AC
- Capacity：5kVA
- HV Source：Epoxy Resin
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030332000
- Production Capacity：2000PCS,Year
Description
Basic Info.
Model NO. GDYD-0505D Control Manual Control Weight 0-100Kg Power Source AC220V Input AC220V ± 10% Frequency 50Hz ± 1 Output voltage 0-5kV, AC Capacity 5kVA HV Source Epoxy Resin Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
Introduction
GDYD series AC Hipot Test Set integrate control unit and HV unit in one device for small capacity requirements. It is suitable for electric power branch, power department of factories,scientific research units, railway, chemical industry, power plants.
Technical Specifications
| Power Supply | AC 220V±10% |
| Frequency | 50Hz±1 |
| Output voltage | 0-5kV, AC |
| Capacity | 5kVA |
| HV Source | Epoxy Resin |
| Output control | Manual control |
| Voltage accuracy | ≤1.5% (F.S) |
| Current Accuracy | ≤1.5% (F.S) |
| Timing range | 0-99H |
| Metering | Digital display, kV meter: AC 0-5kV, mA meter: AC 0-1000mA |
| Humidity | 85% RH |
| Environmental temperature | -20ºC~50ºC |
| Weight | About 75kg |
