• Model NO.：GDYD-5,25D
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Input：AC220V ± 10%
• Frequency：50Hz ± 1
• Output：0-25kV, AC RMS
• Capacity：5kVA (based on selectable)
• HV Source：Insulation oil (Oil type testing transformer)
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030332000
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDYD-5/25D Control Manual Control Weight 0-100Kg Power Source AC220V Input AC220V ± 10% Frequency 50Hz ± 1 Output 0-25kV, AC RMS Capacity 5kVA (based on selectable) HV Source Insulation oil (Oil type testing transformer) Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

Application

Typical applications include testing of transformers, switchgear, cables, capacitors, aerial motors platforms, hot sticks bucket bricks, vacuum bottles and other related equipment like vacuum interrupters, blankets, ropes, gloves, hydraulics hose, instruments transformers generators.

Technical Specifications


Input	AC220V ± 10%
Frequency	50Hz ± 1
Output	0-25kV,  AC RMS
Rating	100%Rated-1minute, 50%-continuous
Capacity	5kVA (based on selectable)
HV Source	Insulation oil (Oil type testing transformer)
Output control	Manual control
Voltage accuracy	≤ 1.5% (F.S)
Current accuracy	≤ 1.5% (F.S)
Timing range	0-99H
Metering	Digital display, kV meter: AC 0-25kV, mA meter: AC 0-200mA
Humidity	85% RH
Environmental temperature	-20ºC~50ºC
Weight	Control Unit: About 20kg Oil testing transformer: About 55kg.
