AC Hipot Test Set AC 1kVA, 5kV
HV Hipot Electric Co., Ltd.- Type：Withstand Voltage Test Set
- Maxcapacity：0-300kv
- Accuracy Grade：1.5%
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：GDYD-0501
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Power supply：AC220V±10%, 50Hz ± 1
- Output voltage：0-5kV AC
- Output current：0- 200mA
- Capacity：1kVA
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030332000
- Production Capacity：2000PCS,Year
Description
Basic Info.
Model NO. GDYD-0501 Control Manual Control Weight 0-100Kg Power Source AC220V Power supply AC220V±10%, 50Hz ± 1 Output voltage 0-5kV AC Output current 0- 200mA Capacity 1kVA Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
General Information
GDYD series AC Hipot Test Set integrate control unit and HV unit in one device for small capacity requirements. It is suitable for electric power branch, power department of factories, scientific research units, railway, chemical industry, power plants.
Technical Specifications
| Power supply | AC220V±10%, 50Hz ± 1 |
| Output voltage | 0-5kV AC |
| Output current | 0- 200mA |
| Capacity | 1kVA |
| Voltmeter accuracy | ≤ 1.5% (F.S) |
| Ammeter accuracy | ≤ 1.5% (F.S) |
| Timing range | 1s -99h |
| Metering | Digital display, kV meter: 0-5kV AC, mA meter:0-200mA AC, A meter: 0-5A AC |
| Operation temperature | -20ºC~50ºC |
| Relative humidity | ≤90%(no condensate), when temperature is 25ºC |
| Weight | About 25kg |
