• Model NO.：GDYD-137D
• Output：0-130kV, 50mA; 0-36kV, 180mA
• Capacity：6.5kVA
• HT Source：SF6 gas (Gas testing transformer)
• Voltage accuracy：≤ 1.5% (F.S)
• Current Accuracy：≤ 1.5% (F.S)
• Humidity：85% RH
• Environmental temperature：-20ºC~50ºC
• Transport Package：Wooden Case
• Specification：120kg
• Trademark：HV Hipot
• Origin：China
• HS Code：9030332000
• Production Capacity：1000PCS,Year

Basic Info.

Model NO. GDYD-137D Output 0-130kV, 50mA; 0-36kV, 180mA Capacity 6.5kVA HT Source SF6 gas (Gas testing transformer) Voltage accuracy ≤ 1.5% (F.S) Current Accuracy ≤ 1.5% (F.S) Humidity 85% RH Environmental temperature -20ºC~50ºC Transport Package Wooden Case Specification 120kg Trademark HV Hipot Origin China HS Code 9030332000 Production Capacity 1000PCS/Year

Product Description

Technical Specifications


Input	AC 220V± 10%, 50Hz, 32.5A, Single phase
Output	0-130kV, 50mA  0-36kV, 180mA
Rating	25mA/90mA, continuous working 33.3kV/120mA, 1hour ON/1hour OFF 50mA/180mA, 5mins ON/15mins OFF
Capacity	6.5kVA
HT Source	SF6 gas (Gas testing transformer)
Output control	Manual control
Voltage accuracy	≤ 1.5% (F.S)
Current Accuracy	≤ 1.5% (F.S)
Timing range	0-99H
Metering	Digital display, kV meter: there is a dial switch, the range is 0-36kVAC if it switches to 36kV, the range is 0-130kVAC if it switches to 130kV mA meter: 0-200mA, 0-2mA(when AC millimeter supplied in HV side)
Humidity	85% RH
Environmental temperature	-20ºC~50ºC
Weight	Control Unit: About 20kg SF6 Testing transformer: About 100kg.
Dimension	Control unit: About 440*340*240mm SF6 testing Transformer: About 450*450*1400mm
