• Model NO.：HT-6021-CD
• Power Source：AC220V
• The Machine′s Standard：ECE R22.05
• Materials：Aluminum and Stainless Steel
• Control Method：PLC Control
• Function：Mian Use to Check Helmet′s Rigid
• Transport Package：Wooden Case
• Specification：ECE R 22.05
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9013809000
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. HT-6021-CD Power Source AC220V The Machine′s Standard ECE R22.05 Materials Aluminum and Stainless Steel Control Method PLC Control Function Mian Use to Check Helmet′s Rigid Transport Package Wooden Case Specification ECE R 22.05 Trademark HOTOTECH Origin Dongguan HS Code 9013809000 Production Capacity 100 Sets Per Month

Product Description

Safety helmet lateral deformation testing equipment
Principle
The helmet is subjected to transverse compressive forces and the deformations measured


Safety helmet lateral deformation testing equipment  Function and feature:
1, According to ECE R 22.05 standard.
2, For testing the rigidity of a helmet, measure the extend of deformation after applying a certain load on a helmet.
3, PLC controlled.

Safety helmet lateral deformation testing equipment  Procedure
The helmet shall be placed transversely between two guided rigid parallel plates of nominal size 300mm*250mm , having their lower edges radiused to 10mm±0.5mm , the brim shall lie outside, but as close to the plates as possible . In the case of helmets without a brim , the lower edge of the helmet shall lie between the plates

An initial force of 30 N shall be applied perpendicular to the plates, so that the helmet is subjected to a lateral force. After 30s the distance between the plates shall be measured ( dimension x )

The force shall be increased by 100 N per minute up to 430 N , which shall be held for 30s , after which the distance between the plates shall again be measured(dimension y )

The force shall be decreased to 25N and then immediately increased to 30N , which shall be held for 30s , after which the distance between the plates shall again be measured (dimension Z)
Measurement shall be made to the nearest millimeter , and the extent of damage, if any , shall be noted. The maximum lateral deformation is the difference between dimension x and y . The residual lateral deformation is the difference between dimension x and z
