• Model NO.：PN-SCTF
• Operation System：Touch Screen
• Standards：ISO9895
• Transport Package：Wood Package
• Specification：ISO, SGS, CE
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang
• HS Code：90248000
• Production Capacity：500sets,Year

Basic Info.

Model NO. PN-SCTF Operation System Touch Screen Standards ISO9895 Transport Package Wood Package Specification ISO, SGS, CE Trademark PNSHAR Origin Hangzhou, Zhejiang HS Code 90248000 Production Capacity 500sets/Year

Product Description

1. Description:
PN-SCT short span compression tester is designed and developed according to ISO9895 to determine the short span compression strength of paper and paperboard. It is used for paper or cardboard for boxes.
With mechanical and electrical integration configuration, the instrument is well-designed using modern mechanical design theory and human engineering design criteria and micro-process.
This instrument has the parameters which are required by the ISO standard, display, memory and printing functions.
2. Features:
1) Pneumatic grips for sample;
2) With statistical function, display the average value, max. value and min.value, standard deviation, coefficient of variation;
3) Adopts high-speed ARM processor, high degree of automation, fast data-collection, fully automatic testing, intelligent judgment function, safe and reliable.
4) Adopts 24digitals high-precision AD converter (Resolution can reach 1/10,000,00) and highly precious weighing sensor, to make sure the data-collection fast and accurate.
5) 7" color touch screen;
6) Modular circuit design, convenient maintenance and replacement.
7) English operation interface.
8) Built-in thermo-printer.
3. Standards:  ISO9895, GB/T 2679.10

4.     Specification:

ITEM	SPECIFICATION
Power supply:	AC220V±10% 5A  50Hz.
Indicator error:	±1%.
Resolution:	0.01 N.
Measuring range:	≤500 N.
Test speed:	(3±1) mm/min.
Clamping pressure:	2300±500N
Apperture between pneumatic clamps:	0.7mm±0.05mm
Display:	7" Touch Screen.
Printer:	Thermal printer.
Data output:	RS232(Standard) / USB(Optional).
Work environment:	Room temp(20  ±  10 )°C.humidity< 85%.
Dimension:	(466 × 410 × 360  )mm(L×W×H).
Net weight:	about 42 kg.
