Made in China 2019 100A Micro-Ohmmeter HV Hipot Loop Resistance Tester

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：0.5
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GDHL-100A
  • Weight：0-100Kg
  • Power Source：AC220V
  • Power supply：AC220V±10%, 50Hz
  • Power consumption：≤500W
  • Current steps：50A, 100A
  • Accuracy：± (readings*0.5%+0.1uΩ)
  • Resolution：0.01uΩ
  • Digital display of resistance：5 1,2 digit
  • Transport Package：Standard Export Wooden Box
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan, China
  • HS Code：9030899090
  • Production Capacity：5000set,Year

Description

Power supply

AC220V±10%, 50Hz

Power consumption

≤500W

Current steps

50A, 100A, other is customized

Measurement range

1-100000μΩ

50A:1μΩ-100000μΩ; 100A:1μΩ-50000μΩ;

Accuracy

± (readings*0.5%+0.1uΩ)

Resolution

0.01uΩ

Digital display of resistance

5 1/2 digit

Output voltage of constant current source

≤5V

Measurement time

Multiple test times can be set.

Power consumption

≤500W

Data storage

1000 sets

Use conditions

-20ºC~40ºC, ≤80%RH (no condensing)

Weight

<5kg
