• Model NO.：XHY-29
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Plywood Case
• Specification：ISO 2813, ISO 7668, ASTM D 523, ASTM D 2457
• Trademark：XHINSTRUMENTS
• Origin：China
• HS Code：9024800000
• Production Capacity：5000 PCS, Year

Measuring angle

20°, 60°, 85°

Standard

ISO 2813, ISO 7668, ASTM D 523, ASTM D 2457, DIN 67 530, JIS Z 8741, BS 3900, BS 6161

Measurement of spot size

20: 10x10mm; 60°: 9x15 mm, 85°: 5x38mm

Resolution ratio

0- 99.9 GU:0.1 GU  100 -2000 GU:1 GU

Measuring range

20°: 0.0 -2,000 GU, 60°: 0.0 -1,000 GU,  85°: 0.0 -160 GU

Repeatability

.0-99.9 GU: 0.2 GU, 100-2,000 GU: 0.2% of indication

Storage

100 sets of standard samples, storing 100 sets of testing samples under each standard sample, with free allocation

Indication error

0.0-99.9 GU:±1.5 GU  100-1,000 GU:±1.5% of indication

Measuring time

0.5 seconds

Measuring mode

Sample measuring, statistical measuring, continuous measuring, and basic measuring

Power Source Management

Automatic Backlight-off , Automatic Power-off

Measuring mode

Sample measuring, statistical measuring, continuous measuring, and basic measuring

Power Source

External direct current +5V power adapter / USB/ 1.5V alkaline battery or nickel- metal hydride battery

Interface Language

Chinese and English

Port

USB 2.0

Weight

520g

Size

163.8mmx58.1mmx88.3mm

1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
