ASTM D3985 OTR-O3 Oxygen Transmission Rate Tester Coulometric Sensor Method
Pubtester Instruments Co., Ltd.- Warranty：12 Months
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Test Range：0.01~6500 (Cc,M2.24h)
Base Info
- Model NO.：OTR-O3
- Resolution：0.001
- Specimen Thickness：≤3 mm
- Number of Specimens：3
- Trademark：Pubtester
- Origin：China
Description
Extended ApplicationClosure Systems Oxygen barrier property of various closure systems for bottles cartons and pouches Solar Back-Sheets Oxygen permeability test of solar back-sheets Plastic Tubes Oxygen permeability test of various sorts of tubes, e.g cosmetic tubes Blister Packs Test oxygen transmission rate of the whole blister packs Automotive and Small Engine Fuel Tanks Permeability of plastic fuel tanks Battery Plastic Shell Oxygen transmission rate of battery plastic shell
Technical Specifications
Standards
ASTM D3985, ASTM F2622, ASTM F1307, ASTM F1927, ISO 15105-2, DIN 53380-3, JIS K7126-B, YBB 00082003, GB/T 19789
Configuration
Standard configuration: Instrument, Vacuum grease, Sampler, Calibration film, Nitrogen/Oxygen pressure regulator
Optional configuration: Container test accessories, Container test temperature controller, Air Compressor
Note: Nitrogen and Oxygen are prepared by customer.
About Us
Established in Jinan, China, Pubtester Instruments Co., Ltd has developed into a major manufacturer and supplier of flexible packaging testing instruments in China. In the year of 2020, Pubtester launched a series of testing instruments specilized in medical device (medical dressings, syringes, catheters, gloves and aseptic packaging, etc), which meet the increasing testing demand for medical industry since 2019. Pubtester has its own packaging testing center, equipped with more than 80 sets of testing instruments, which can perform barrier, force and strength, heat sealing, hot tack, coefficient of friction, thickness, tearing, impact, heat resistance, leakage, flex durability , adhesion, color, fastness and other testing items, and provide testing services to customers. Pubtester has a great technical team of professionals, all of whom have more than 10 years experience in packaging testing industry, which provide our customers with comprehensive technical services and solutions all the time. Pubtester, is always dedicated to be the packaging testing expert by your side.
Technical Specifications
| Specifications | OTR-O3 |
| Test Range (film) | 0.01~6500 (cc/m2.24h) |
| Resolution | 0.001 |
| Permeable Area | 50 cm2 (Customizable) |
| Specimen Thickness | ≤3 mm |
| Number of Specimens | 3 |
| Number of Sensor | 3 |
| Test Mode | Three chambers independent |
| Temperature Control Range | 5ºC~95ºC (Temperature control device is optional) |
| Temperature Accuracy | ±0.1ºC |
| Carrier Gas | 99.999% High-purity Nitrogen (outside of supply scope) |
| Carrier Gas Flow | 0~100 mL/min |
| Carrier Gas Pressure | ≥0.2MPa |
| Port Size | 1/8inch metal tubing |
| Instrument Dimension | 740 mm (L) x 415 mm (W) x 430 mm (H) |
| Power Supply | AC 220V 50Hz |
| Net Weight | 50 kg |
Standards
ASTM D3985, ASTM F2622, ASTM F1307, ASTM F1927, ISO 15105-2, DIN 53380-3, JIS K7126-B, YBB 00082003, GB/T 19789
Configuration
Standard configuration: Instrument, Vacuum grease, Sampler, Calibration film, Nitrogen/Oxygen pressure regulator
Optional configuration: Container test accessories, Container test temperature controller, Air Compressor
Note: Nitrogen and Oxygen are prepared by customer.
