Vertical Thermal Shock Chamber with Separate Hot and Cold Cycling Temperature Zones

Guangdong Komeg Industrial Co., Ltd.
  • Power Supply：380V
  • Certification：CE, TUV, ISO
  • Warranty：1 Year
  • Frequency Range：10-80Hz
  • Frequency Accuracy：+,-0.5Hz
  • Acceleration Range：0~11g(Peak)

Base Info

  • Model NO.：VS-5060
  • Maximum Payload：80kg
  • Test Mode：Fix; Sweep;Multi-Random
  • Displacement Range：0~2.8mm P-P Adjustable
  • Table Size：500*600(Mm)
  • Test Program Number：No Limit
  • Test Time：No Limit
  • Vibration Dimensions：W625*D525*H690mm
  • Transport Package：Strong Plywood Case for Long Journey Delivery
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets,Year

Description

Main technical specification

2,Performance:( Water-cooled, water temperature is +25 ° C, no load)



2.1 Low temperature shock range

-70ºC~-10ºC



2.2High temperature shock range

+60~+200ºC



2.3 Shock range

High temperature:+60~+150ºC ;Low temperature: -50ºC~-10ºC



2.4 Temperature stability

±0.5ºC



2.5 Temp. Uniformity

±2.0ºC



2.6 Temperature steady time

-50ºC~150ºC about 5min,With load 10KG plastic IC,, High



temperature and low temperature steady for each 30 min(sensor



placed in the unit outlet)

Structure Features



3.1 Workspace volume

W 700 × H 600 × D 600 mm



3.2 Exterior size

Approx W 1750 × H1960 × D 2000 mm



3.3 Inner material

Stainless steel (SUS #304)
