Transformer Oil Bdv Breakdown Voltage Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Standards：IEC60156,Is6792,BS5874, Astmd877, Astmd1816
  • Output Voltage：AC 0V~100kv
  • Measurement Precision：3%Rdg+0.3%Fs
  • Test Times Setting：9
  • Temperature Measurement：No
  • Maximum Storage Capacity：100 Groups

Base Info

  • Model NO.：GDYJ-502
  • Display：LCD Screen
  • Printer：Yes
  • Power Supply：AC 220V±10% 50Hz,60Hz
  • Relative Humidity：80%Rh
  • Dimension：620*430*330mm
  • Transport Package：Standard Wooden Case
  • Specification：620*430*330mm, 41kg
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：500 Set

Description

41kg



Test Options

1) IEC60156/IS6792/BS5874/VDE0370-5

2) User-defined

3) 5 minute test

4) ASTMD877

5) ASTMD1816

6)JIS C 2101-99(S)

7) Proof 'A'

8)Proof 'B



Warnings

  • If the tester shows the text "door open, please close the door", it is mean that the test is paused. You would have to close the door for safe. Otherwise the tester will not work.
  • It is very dangerous that open the insulating door when the tester is working.

Features:

  • LCD screen can display test procedure and test result;

  • All the human interaction operations complete by the rotating mouse;

  • It is very easy for customers to measure the breakdown voltage of all kinds of oil;

  • You can print the test result by the micro printer internal the tester;

  • Meanwhile, you can upload the test data to PC from RS232 for data analyzing;

  • The special circuit design makes the tester has a good performance at stability and anti-noise.

Transformer Oil Bdv Breakdown Voltage Tester Our Services

Pre-sale Service:

♣Inquiry will be replied within 24 hours.

♣Welcome to visit our factory.

♣Technical datas and operation manual sent for evaluation.

After-sale Service:

♣Training how to install the machine, training how to use the machine at our factory.

♣Engineers available to service machinery overseas at customers' cost.

FAQ
  • What's the delivery lead time?

"For most of the products, delivery lead time is 10 days after the order is confirmed; For some customized products, please check with the sales person."

  • What's the payment term?

"For total amount below USD3,000.0, payment term is 100% T/T as deposit; For total amount above USD3,000.0, payment term is 30% T/T as deposit, the balance before delivery; The payment term is also negotiable."

  • What's the warranty period?

"Warranty period is 1 year"
