30ton/300kn Concrete Cement Brick Compression Bending Flexural Testing Machine

Jinan Kason Testing Equipment Co., Ltd.

After-sales Service：Standard
Warranty：1 Year
Max Diameter of Workpiece：900mm
Mass Scope of Workpiece：1000kg
Type：Compression Testing Machine
Maxcapacity：<1000KN

Base Info

Model NO.：YAW-300C
Accuracy Grade：1
Load Way：Electronic Load
Loading Method：Static Load
Display：Digital
Control：Computer Control
Weight：100-500Kg
Power Source：AC220V
Oil Cylinder Position：Under
Accuracy：1 Class
Compression Stroke：80mm
Distance Between Upper/Lower Plate：220mm
Plate Diameter：Dia 140mm
Transport Package：Standard Shipping Case
Specification：535X1110X1420mm
Trademark：Hensgrand or OEM
Origin：Jinan, Shandong, China
HS Code：9024800000
Production Capacity：500 Sets,Month

Description

Overview Product Description

1. Application

YAW series compression and felxural testing machine is mainly used for the the compressive strength and compressive properties test of brick, stone, cement, carbon, concrete oil proppant and other materials.This machine is specially designed for the customers group who have high requirements for test process and continuous working time.
Widely used by water conservancy department, carbon materials research, oil exploration, colleges and universities and other institute.
1class Control wayConstant stress and constant strain,
constant displacement closed loop control modeLoad range2%-100%FSLoad accuracyBetter than ≤±1%Displacement value accuracyBetter than ±0.5%Displacement value resolution0.005mmDisplacement rate control adjusting range0.005~25mm/minEffective compression stroke80mmMax distance between upper and lower plate220mmCentral distance between the two columns350mmSize of upper and lower platenDia 140mmPower220V, 1.5kW, 50Hz 30ton/300kn Concrete Cement Brick Compression Bending Flexural Testing Machine
