GDCT-103B CT On Site Analyzer Current Transformer Calibrator

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：0.5
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GDCT-103B
  • Weight：0-100Kg
  • Power Source：AC220V
  • Transformation Ratio Range：5A,5A~25000A,5A(5A,1A~5000A,1A)
  • Error Measurement Range：5A,5A~10000A,5A(5A,1A~5000A,1A)
  • Accuracy Range of Tested CT：1.0, 0.5, 0.5S, 0.2 and 0.2S
  • Transport Package：Standard Export Plywood Case
  • Specification：ISO
  • Trademark：HV Hipot
  • Origin：Wuhan, China

Description

Measurement errorRated CurrentTurns Ratio (±%)Angel Error
 (±′)5%0.10420%0.054100%0.052120%0.052200%0.052DC Resistance0.0-0.1Ω  ±3%
0.1-50Ω  ±1%CT Secondary Burden1-25Ω  ±2%VerificationsVoltage range: 0-100V
Ratio error: 0.001%~3% (100V)
Angle error: 0.00′-50′(100V)
Error: DX=±(2%* X+2%*Y±2digitals)
DY=±(2%*X+2%*Y±2digitals)Conductance 0.1mS-99.9mSErrorDX=±(2%*X+2%*Y±2digitals)
DY=±(2%*X+2%*Y±2digitals)Working conditionsAC220V±10%, 50Hz±2%Working environmentTemperature: 0ºC~40ºC, Humidity: ≤85% (25ºC)Dimension & Weight323*275*135mm, ≤5kg
