Capacitance & Dissipation Factor Measuring Bridge
Nantong Zhenhuan Trade Co., Ltd.- Transport Package:Sea Worthy Wooden Case
- Trademark:ZHENHUAN
- Origin:China (Mainland)
Base Info
- Model NO.:HD6000
- Production Capacity:20 Set Per Month
Description
1
Service conditions
-5°C ~ 40°C
RH<80%
2
Principle of anti-jamming
varying frequency
3
Power supply
AC220V +/-10% (no limit on frequency)
4
HV output
voltage
0.5~10kV
precision
5%
Max. current
140mA
Capacity
1000VA
5
Self-exciting power
AC 0~30V
45Hz/55Hz
Max. current
15A
6
Resolution ratio
tgδ 0.001%
Cx: 0.1pF
7
Precision
Δtgδ
+/- (reading x 1.0% + 0.040%)
ΔCx
+/- (reading x 1.0% +1.0pF)
8
Measuring range
tgδ
No limit
Cx
15pF < Cx < 100000pF
10kV
Cx < 30,000pF
5kV
Cx < 60,000pF
1kV
Cx < 100,000pF
For CVT
Cx < 100,000pF
9
Memory size
Can store 40 units test data
10
Dimension
470 x 320 x 390mm (L x W x H)
11
Weight
30kg
We Nantong Zhenhuan Trade Co., Ltd. is certified by TUV, BV, SGS, good reputation and credit. We can provide you not only good qualitycapacitance & dissipation factor measuring bridges but also good after-sale service.
