• Model NO.：GDKS-205
• Repeatability：≤150ºC 3ºC; >150ºC 5ºC
• Max. power：400W
• Thermometric sensor：PT resistance (A Grade PT100)
• Flash fire sensor：Ion detection ring
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：2000 Sets,Year

Basic Info.

Model NO. GDKS-205 Repeatability ≤150ºC 3ºC; >150ºC 5ºC Max. power 400W Thermometric sensor PT resistance (A Grade PT100) Flash fire sensor Ion detection ring Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 2000 Sets/Year

Product Description

GDKS-205 automatic open cup flash point tester is the device testing open cup flash point for petroleum products. It use module design which one host can control several testing furnace, to test different samples at the same time or separately. The testing furnace port can be connected to the host disorderly. It widely used in the field of railway, air company, power, petroleum and research department.

Features

• 320*240 TFT LCD touch screen.
• With high speed signal processor control, reliable and high accuracy.
• One host can control several test furnace to test several samples at one time, which will save testing time.
• Detection, ignition, alarm, cooling, printing, the whole testing process is completed automatically.
• Platinum electric wire or gas ignition.
• Built-in atmosphere pressure sensor, auto-measure and calibrate result.
• Self-adaptive PID control calculation, automatic adjusting temperature rise curve according to standard requirements.
• With fault auto-detection alarm function.When sensor fault, sample mistake, temperature over value, the instrument will stop automatically and alarm.
• Calendar clock with temperature compensation, and accurate travel time, automatically recording the date and time of measurement, in a power down state can be operation for more than 10 years.
• Built-in high speed thermal printer.
• Store up to 255pcs history records.
• Built in multiple execution criteria for selection.

Specifications


Temperature measure range	-59.9ºC-399.9ºC
Temperature control range	room temperature 399.9ºC
Repeatability	≤150ºC 3ºC; >150ºC 5ºC
Resolution	0.1ºC
Accuracy	0.5%
Thermometric sensor	PT resistance (A grade PT 100)
Flash fire sensor	Ion detection ring
Power voltage	AC 220V±20% 50Hz±10%
Max. power	<500W
Environmental temperature	-10ºC-40ºC
Relative humidity	≤85%RH
Ignition method	gas flame or electric ignition
Weight	14kg
Dimension	440*280*290mm
