Fully Automatic Electronic Single Yarn Tensile Strength Tester

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Type：Strength Testing Machine
  • Maxcapacity：12000cn
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：XHL-02F
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Touch Screen+ PC Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case
  • Specification：150kgs
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

Max Measurement Force

6000CN

Linear Deviation

0.05%

Load Cell Accuracy Class

0.05%

Gauge Length

250mm±1mm,500mm±1mm

Pretension

1cN-100cN

Elongation

when at 250mm gauge length, max elongation is 220%

when at 500mm gauge length, max elongation is 60%

Accuracy

Within ±1% of applied force

Tensile Speed

50mm/min-5000mm/min

Tex

1-999.9 random setting

Working Pressure

0.4Mpa-0.8Mpa

Power

AC110/220V  50/60Hz

Dimension

1295mm×550mm×450mm

Weight

140kg


Fully Automatic Electronic Single Yarn Tensile Strength TesterFully Automatic Electronic Single Yarn Tensile Strength Tester1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
