Breakdown Voltage Bdv Testing Device Transformer Insulating Oil Testing Kit

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.

After-sales Service：Yes
Warranty：Yes
Output Voltage：AC 0~80kv
Rate of Voltage Rise：2kv,S±10%
Measuring Precision：3%Rdg+0.3%Fs
Test Times Setting：1-9

Base Info

Model NO.：GDYJ-502
Display：256*128 LCD
Transport Package：Wooden Case
Specification：71*42*53CM
Trademark：Gold
Origin：Chongqing
HS Code：9031809090
Production Capacity：300PCS,Month

Description

1 Breakdown test of user-defined2 Proof test3 Calibration interface for customers4 Unloading data to PC and making word report automatically.5 Result print

Specifications:

1Output voltageAC 0~80KV/AC 0~100KV2Rate of voltage rise2KV/s±10%3Measuring precision3%RDG+0.3%FS4Test times setting 1~95Mixing time setting 0~99 second6Waiting time setting0-9 minute 59second7Maximum storage capacity100 groups of test data8Test standardsIEC601569Display256*128 LCD10Rated power supplyAC 220V±10% 50Hz/60Hz11Environment temperatures 0-50°C 12Relative humidity≤80%RH13Size 420×380×410mm314Weight28kg

GDYJ Breakdown Voltage Bdv Testing Device Transformer Insulating Oil Testing Kit

Model	GDYJ-501	GDYJ-502	GDYJ-502A
Output Voltage	AC 0~80KV/0~100KV	AC 0~100KV	AC 0~80KV
Rate of Voltage Rise	2KV/s±10%	0.5/2/3/5 KV/s±5%	2KV/s±10%
Max. Time Setting	0~9mins	9mins	0~99 seconds
Test Precision	3% RGD+0.3%FS	3% RGD+0.3%FS	3% RGD+0.3%FS
Max. Data Storage	100 groups	100 groups	50 groups
Power Supply	AC220V±10% 50/60Hz	AC220V±10% 50/60Hz	AC220V±10% 50/60Hz
Environment Temp.	0~50Centigrade	0~50Centigrade	0~50Centigrade
Related Humidity	<80%RH	<80%RH	<80%RH
Dimension	420380410mm	620430330mm	420380410mm
Weight	28kg	41kg	28kg
