• Model NO.：WDW-50
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Computer
• Control：Computer Control
• Weight：500-1000Kg
• Power Source：AC220V
• Oil Cylinder Position：Without But with Motor
• Tensile Space：Can Customized
• Grip：Wedge, Winding, or Customized
• Application：Tensile, Compression, Bending, Shear, etc
• Certificate：Ce ISO
• Waranty：12 Months
• Transport Package：Standard Exporting Plywood Case with Free Fumigati
• Specification：700*500*2000mm
• Trademark：HST
• Origin：China
• HS Code：9024109000
• Production Capacity：100set,Month

Four-column floor or desk model,
(upper is compression and lower is tensile)CoverAll aluminum alloyControl methodComputer controlLoad accuracyClass 1Class 0.5Class 1Class 0.5Load range2%~100%F·S0.2%~100%F·S2%~100%F·S0.2%~100%F·SLoad resolution1/300000Rang of deformation4%-100%FSResolution of deformation0.04umAccuracy of displacementWithin±0.5%of indicating loadResolution of displacement0.01mmTest speed(mm/min)0.05-1000 stepless arbitrary settingTensile space(mm)800(can be customized)Compression space(mm)800(can be customized)Test width(mm)400(can be customized)Workbench thickness(mm)30Base height(mm)210Working environmentRoom temperature 10ºC~30ºC,relative humidity≤80%Power supplyAC220V±10%,50Hz/60Hz(can be customized)GripsWedge type, plate type and other grips as consumer's demandDimension(mm)740*420*1720
