• Model NO.：GW-026B
• Accuracy Grade：0.5
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Computer
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：Electric Control
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-026b
• Test Speed：(0.3±0.03)M,S
• Dimension：1060*670*980 mm
• N.W：300 Kg
• Standard：Satra TM144 ,En ISO 13287
• Max. Normal Force：1000n
• Static Contact Time：0~5s
• Vertical Force Sensor：1.25kn
• Horizontal Force Sensor：0.85kn*2
• Transport Package：Standard Export Safety Packing
• Specification：1060*670*980 mm
• Trademark：Great Win
• Origin：China
• HS Code：9024800000
• Production Capacity：500 Pieces,Year

Basic Info.

Model NO. GW-026B Accuracy Grade 0.5 Load Way Electronic Load Loading Method Dynamic Load Display Computer Control Computer Control Weight 100-500Kg Power Source AC220V Oil Cylinder Position Electric Control Packaging Wooden Case Export Markets Global Model No Gw-026b Test Speed (0.3±0.03)M/S Dimension 1060*670*980 mm N.W 300 Kg Standard Satra TM144 ,En ISO 13287 Max. Normal Force 1000n Static Contact Time 0~5s Vertical Force Sensor 1.25kn Horizontal Force Sensor 0.85kn*2 Transport Package Standard Export Safety Packing Specification 1060*670*980 mm Trademark Great Win Origin China HS Code 9024800000 Production Capacity 500 Pieces/Year

Product Description

GW-026B Slip resistance testing machine

•Brief introduction:
Slip resistance testing machine is used to determine the slip resistance of conventionally soled safety, protective and occupational footwear on different floors (such as ceramic tile, stainless steel or carpet). It can be used for test the  SRA,SRB,SRC friction performance .It is not applicable to special purpose footwear containing spikes, metal studs or similar.


•Technical Specifications:


Max. normal force	1000N
Max. horizontal force	1000N
Sliding speed	(0.3±0.03)m/s
Static contact time	0~5s
Vertical force sensor	1.25KN
Horizontal force sensor	0.85KN*2
Test floor	Compressed ceramic tile floor, stainless steel and carpet
Power supply	AC220V 50Hz
Dimensions	1010×670×1900mm
Weight	300kg

•Standard for:
 SATRA TM144 ,EN ISO 13287,GB/T 28287

•Attached accessories:
2pcs PVC test table
1pc standard die mould



What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
