• Model NO.：HJ-80
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-80 Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product Usage:
The low temperature and low pressure test chamber mainly provides temperature and humidity change environment for scientific research and production units such as aerospace, aviation, petroleum, chemical industry, automobile, ship, electronics, communication, etc. Provide reliability testing, product screening, etc. for the safety testing of electronic components. It is widely used in high temperature test, low temperature test, temperature-low pressure test function of various connectors, cables, micro-motors, etc.

Fulfill the standard:
3.1.GB/T 2423.1-2008 Test A: Low temperature test method
3.2. GB/T 2423.2-2008 Test B: High Temperature Test Method 3.3. GB/T2423.3-2008 Constant Damp Heat Test
3.4. GB /T2423.42008 Alternating Damp Heat Test 3.5. GB /T2423.21-2008 Low Pressure Test Method
3.6.GB/T2423.22-2008 test Nb temperature change test
3.7.GB/T2423.25-2008 test Z/AM: low temperature/low pressure comprehensive test;
3.8. GB /T2423.26-2008 test Z / BM; high temperature / low pressure comprehensive test;
3.9.GJB150.2A-2009 Low pressure (altitude) test and other test standards


technical parameter
temperature range	60ºC~+150ºC
temperature fluctuation	≤±0.5ºC (at normal pressure, no load, constant state)
temperature uniformity	≤2ºC (at normal pressure, no load, constant state)
temperature deviation	≤±2ºC (at normal pressure, no load, constant state)
Heating and cooling rate	Air temperature: -60ºC-+150ºC, the whole process average ≥1ºC/min, normal pressure, with load of 10kg aluminum ingot;
	Air temperature: +150ºC-60ºC, the whole process average ≥1ºC/min, normal pressure, with a load of 10g aluminum ingot
pressure range	normal pressure~0.5kPa (common pressure 62kPa, simulated altitude 4km)
buck rate	normal pressure~1.0kPa depressurization time≤30min
	pressure recovery rate: ≤10.0kPa/min
fast buck	rapid decompression: 75.2kPa--18.8 kPa ≤15s
pressure deviation	when the pressure is ≥40KPa: ≤±2KPa
	when the pressure is 4KPa~40KPa: ≤±5%
	when the pressure is ≤4KPa: ≤±0.1KPa
rate of change of air pressure	K15kPa/min (adjustable)
fulfill the standard	CB/T 2423.21-2008 Basic environmental test procedures for electrical and electronic products  Test method for low air pressure
acceptance Criteria	CB/T5170

The operating technical data of the above products are all at room temperature of 20 ºC except for the temperature recovery time, relative humidity ≤ 85R. H, (cooling water temperature 5~28 ºC, water supply pressure at 0.1Mpa~
0.3Mpa), the test box is empty, and the temperature/pressure is constant for two hours.
