• Model NO.：HJ-56
• Turntable Load-Bearing：More Than 2000kg
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-56 Turntable Load-Bearing More Than 2000kg Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product Usage:
Battery pack simulation high-altitude test chamber is used to simulate and evaluate PACK level battery packs and systems in vacuum and low pressure(i.e. high altitude) safety performance. Present the actual use of battery packs or systems in the laboratory, find and solve problems, optimize product design, and improve product quality.

Device Description:
The battery pack simulation high-altitude test box is mainly used to simulate and evaluate the safety of PACK-level battery packs and systems under vacuum and low pressure (ie high altitude) conditions
can. The battery pack high-altitude testing machine simulates that the battery is placed in a low-pressure box, and the air pressure in the test box is adjusted to an altitude of 4000m or the same altitude. , automatically keep the air pressure in the box constant, and realize the automatic termination of the test.
Present the actual use of battery packs or systems in the laboratory, find and solve problems, optimize product design, and improve product quality.

Executive standard GB / T 31467.3-2015/
"Lithium-ion power battery packs and systems for electric vehicles Part 3: Safety requirements and test methods" 7.12 High altitude test
  GB/T 31485-2015/
"Safety Requirements and Test Methods for Power Batteries for Electric Vehicles" 6.2.11&6.3.11 Low Pressure Test
  GB/T 31486-2015
"Electrical performance requirements and test methods of traction batteries for electric vehicles"
  GB 31241-2014 "Safety Requirements for Lithium-ion Cells and Battery Packs for Portable Electronic Products"
  UL 1642:2012 "Lithium Battery Standard" UL 2054:2012
"Household and Commercial Battery Packs"
UN38.3 (2012)
Recommendations on the Transport of Dangerous Goods - Manual of Tests and Criteria Part 3
IEC62133-2012
"Safety Requirements for Batteries and Battery Packs Containing Alkaline or Non-Acid Electrolytes"


Technical parameter
Test pressure adjustable range	10Kpa~101.3Kpa
Way to control	PLC touch screen man-machine interface control + computer remote control (dual control mode)
Inner box material	SUS304# stainless steel plate + bottom square tube channel steel reinforcement,  stainless steel plate thickness 10mm
The load-bearing capacity of the bottom  plate of the test box	≥2200kG
Outer box material	Cold-rolled steel sheet paint treatment
Test space size	W2000XD3000XH2000mm
Equipment box size	W2500XD4000XH3000mm (excluding the controller protruding part)
Turntable load-bearing	More than 2000kg
Turntable table size	W1500XD2000XH200mm
Packing list	Single door, box door with locking device
Box door lock	The holder is a strong cold storage door handle, with a locking device installed,  with sufficient rigidity and strength, with strong explosion-proof hinges, the number is 4
Door system seal	Select high-purity silicone rubber raw material, good sealing effect
Lighting system	The top of the test chamber is equipped with 2 LED explosion-proof lighting lamps,  which can be dustproof, explosion-proof, fireproof, and the explosion-proof lamp shell is easy to replace
Vacuum degree display	Digital display vacuum degree control table, the digital display method is intuitive and easy to set
Timing Display and Control	PLC man-machine interface display and control time
Vacuum time	Drop from 101.3kPa to 11.3kPa within 5 minutes
Vacuum degree resolution and control accuracy	0.1Kpa
Pressure relief method	Manual pressure relief and automatic pressure relief
Record function	The sampling frequency is up to 1Hz, which can record the detection and setting test curves,  data, operation records, alarm records within 12 months, and can be printed
Pressure relief protection	When the pressure of the gas in the box rises, the pressure sensors near the pressure relief  port can quickly open the pressure relief port at the top, discharge the gas and heat,  and reduce the pressure in the box.
Use air source	0.8~1MPA
Using electric	AC380V50HZ
Power	15KW

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
