Liquid and Crude Oil Densimeter Density Tester with Portable Cooler

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Display：Digital
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Under
  • Transport Package：Wooden Case

Base Info

  • Model NO.：GD-1884A
  • Specification：300mm*340mm
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：200units,Month

Description

1. Power supply:  AC(220±10%)V, 50Hz2. Dimension of bath: 300mm×340mm3. Capacity of cylinder: 500ml4. Heating power:  700W, 1000W5. Temperature controller:

(1) Range:  Ambient to 100ºC

  (2) Accuracy:  ±0.2ºC

  (3) Sensor:  Pt100

6. Thermometer:  Mercury-in-glass thermometer. Scale division is 0.2ºC.7. Dimension:  560mm×380mm×580mm



Portable cooler

1.Power supply:     AC(220±10%)V, 50Hz

2.Cooling Power:    180W

3.Refrigeration:   Totally enclosed type compressor

4.Refrigerant:     R134a,environment friendly

5.Ambient temperature:    (5~35)ºC

6.Relative humidity:      ≤85%

7.Dimension:      450mm×400mm×300mm

Liquid and Crude Oil Densimeter Density Tester with Portable Cooler
