• Model NO.：XHET2000
• Weight：47kg
• Transport Package：Standard
• Specification：L W; H 670; 480; 420mm
• Trademark：STI
• Origin：Zhejiang
• Production Capacity：100PCS,Month

Basic Info.

Model NO. XHET2000 Weight 47kg Transport Package Standard Specification L W; H 670; 480; 420mm Trademark STI Origin Zhejiang Production Capacity 100PCS/Month

Product Description

XHET2000 Elongation Tester XHET2000 Elongation Tester
1.Implementation standard :IEC60851-3,Inspection standard :JB/T4279.3.

2.It is applied to metal wire whose stretch breaking force not bigger than 3000N.

3.32 bit RAM control system

4.Clamps are designed according to characteristics of aluminum wires ,thus can avoid sample breaking in clamps completely .Clamps can scrape paint film automatically after pressing the sample tightly .

5.Clamp will stop moving when the sample is snap .Error between the percentage elongation displayed on LED and the actual percentage elongation is less than 1%.

6.The results are accurate to one decimal place .

7.The LCD screen can indicate the testing steps and display the testing result .

8.All test data and spool product information can be automatically transmitted to the top position machine and automatically saved and analyzed by QME enameled wire quality management system .

9.Main technical parameters

Speed of elongation	(300±60)mm/min
Distance between the two clamps	(200±0.5)mm
Moving distance of clamps	>156mm
Input power supply	AC220V±10% 50Hz
Consumed power	≤120W
Dimension	L×W×H 670×480×420mm
Weight	47kg
