• Model NO.：HZYZ-209
• Waveform Max Saving Time：6.4 Second
• Measurement Accuracy：0.1Ω~1Ω±0.1Ω
• Time Error：△≤±1%
• Power：200W
• Transport Package：Wooden Box with Wrapping Film
• Specification：410x320x200mm²
• Trademark：United
• Origin：Wuhan, China

Basic Info.

Model NO. HZYZ-209 Waveform Max Saving Time 6.4 Second Measurement Accuracy 0.1Ω~1Ω±0.1Ω Time Error △≤±1% Power 200W Transport Package Wooden Box with Wrapping Film Specification 410x320x200mm² Trademark United Origin Wuhan, China

Product Description

I.Product Description:
HZYZ-209 type power transformer on-load voltage regulation tapping switch tester applies to measure and analyze the loading tap switch property index of power transformer and special transformer.

II.Product Features:
1.Ray oscilloscope function
2.Strong comprehensive ability
3.Good anti-interference function
4.Data saving, data communication
5.Three way independent test power supply
6.Printing output. Equipped with high speed paper printer.
7.Monitor: 240 128T, T6963 C controller
8.Process part: high speed 8 bit microprocessor,512Kbyte data storage which can save 128 groups waveform
9.High speed A/D converter, the highest sampling rate is up to 400KHz

III.Product Parameters:

Output Current	1, 0.5A	Time Error	△≤±1%
Sampling Rate	10~20kHz	Power Source	220V±10%
Waveform Max Saving Time	6.4 second	Power	200W
Transition Resistance Measurement Range	Y/O transformer1-40Ω Y transformer1-20Ω	Dimension	410x320x200mm²
Measurement Accuracy	0.1Ω~1Ω±0.1Ω 1Ω~50Ω, △≤±5%	Weight	20kg


Company Profile:
Wuhan Hezhong Electric Equipment Manufacture Co., Ltd is a high-tech enterprise professionally engaged in R & D, manufacture and marketing of power testing products, instruments, power industry automation systems for 20 years.We export completed set to Korea, Singapore, Vietnam, India, Ecuador, Paraguay, Pakistan, Philippines, Russia, Italy, Austria, Portugal, Chile such as PD test system, impulse voltage generator, temperature rising test system, transformer comprehensive test system, cable fault detect system and varies of instruments for transformer, circuit breaker, switchgear, lightning arrestor, insulator, cable, battery,SF6 gas and so on.
