• Model NO.：KMH-408 series
• Exterior Material：Stainless Steel
• Insulation Material：Rigid Polyurethane Foam
• Inner Size：W 920 * H 680*D 500 mm
• Outer Size：W 1280 * H 1980 * D 1150 mm
• -40ºC up to +85ºC：About 45min
• +20ºC to -40ºC：About 60min
• Tmeprature Range：-40~150c
• Explosion Proof System：Included
• Transport Package：Plywood Case
• Specification：Standard and customized, ISO9001, SGS, CE, TUV, UL
• Trademark：KOMEG
• Origin：China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

ModelKMT-408L420L chamber volumeTemp. range -40°C ~150°C Display resolution0.1°CTemperature stabilityHigh±0.5°C ,low ±1.0°CTemperature uniformity ±2.0°CHeat up time -40°C ~+100°C,within 45 minPull down time -20°C ~-40°C,within 60 minHumidity range20~98%R.H,(standard),   '10~98%R.H,(with humidifier)Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.HInterior Dimension(mm)700W*750H*800DExterior Dimension(mm)980W*1940H*1740D Interior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolTotal power  6KW(heater 3KW included)Max current17AWater Consumption1L/hrAmbient Temp.+5°C ~+35°C Power Supply AC 380V±10%50Hz ,3 phase 4 wires +Ground WiresWeight 400KGSight window size460*560mmSample holder 2 pcsFittingscable port(portΦ50mm)*1, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker,over pressure,over heat&over current protect,over temp. protect, over load protect for blower, dry heat protect Control SystemBalanced Temperature & Humidity Control (BTHC)SystemRefrigeration systemAir Cooled (Water Cooled is option)Hermetic compressor  Hermetic compressor
Single stage refrigeration system,
CFC-Free refrigerant(HFC-507/HFC-23)CFC-Free refrigerant(HFC-507/HFC-23)Controller7-inch LCD Touch Screen panel                                                                        Operation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesNote:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
