• Model NO.：GD-6538B
• Product Name：Low Temperature Lab Distillation Apparatus 0~60cel
• Standard：ASTM D86, GB,T6536
• Measurement Range：0~60celsius
• Refrigeration：Yes
• Single/Double Unit：Double
• Atmospheric/Vacuum：Atmospheric
• Usage：Determine The Distillation Characteristics
• Delivery Time：10 Working Days(If Urgent, We Can Push)
• Test Parameter：Petroleum Products
• Transport Package：Wooden Case for Distillation Apparatus
• Trademark：GOLD
• Origin：Chongqing, China
• Production Capacity：100 Sets, Month

low temperature ASTM D86 Distillation apparatus adopts low temperature and double units working mode. The minimum temperature can set to 0ºC. It can do test for one sample or two samples at same time.It highly improves the work efficiency.

low temperature ASTM D86 Distillation apparatus adopts digital temperature controller, stainless-steel heater, new type refrigeration compressor and electric stirrer to constitute constant temperature bath. The temperature in the bath is uniform,can fully meet the requirements of test.

low temperature ASTM D86 Distillation apparatus adopts special designed structure, cooling speed is fast.The bath temperature can cool down from room temperature to 0ºC within 50 minutes.

low temperature ASTM D86 Distillation apparatus adopts special heating furnace to ensure the safety of test. Heating power can be continuously adjusted to meet the requirements of test

Note: The temperature control is to control the temperature of condensate in the condenser pipe.

Ambient temperature:

≤30ºC

Relative humidity

≤85%

Cooling system

New type refrigeration compressor

Maximum power consumption

4000W

Dimension

730*530*580mm
