• Model NO.：GW-066A
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Electric Control
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-066A
• Output Voltage：0.0-15.0 Kv R.M.S
• Test Voltage：1.0-15.0 Kv R.M.S
• Cable Diameter：0-25mm
• Maximum Load Current：4 Ma Resistive ,40mA Capacitive
• Output Frequency：2.5-3.5 Khznormal
• Electrode Lengths：Bead Chain 120mm
• Signal Cable Lengths：5m
• Transport Package：Standard Export Safety Packing
• Specification：15kg
• Trademark：Great Win
• Origin：China
• HS Code：9024800000
• Production Capacity：500 Sets,Year

Basic Info.

Model NO. GW-066A Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Electric Control Packaging Wooden Case Export Markets Global Model No Gw-066A Output Voltage 0.0-15.0 Kv R.M.S Test Voltage 1.0-15.0 Kv R.M.S Cable Diameter 0-25mm Maximum Load Current 4 Ma Resistive ,40mA Capacitive Output Frequency 2.5-3.5 Khznormal Electrode Lengths Bead Chain 120mm Signal Cable Lengths 5m Transport Package Standard Export Safety Packing Specification 15kg Trademark Great Win Origin China HS Code 9024800000 Production Capacity 500 Sets/Year

Product Description

        Wire High Frequency Spark Test Machine(GW-066A)

Specifications:
Test Voltage: 1.0~15.0KV. Cable Diameter: 0~25mm. Output Frequency: 2.5-3.5kHz normal. Fast recovery time after fault (0.1s)
The Sine Wave Spark Tester is a fast and reliable instrument used in distinguish wire faults and detecting bare wires. Its high-speed fault detection feature gives you prompt information without worsening the condition of the wire after the test.
The use of high frequency (3kHz) enables a traditional commercial power frequency bead chain electrode to be shortened to 120mm HS015E Model.
The Sine Wave Spark Tester is quality-assured to meet your needs.

Basic Function
Fast recovery time after fault (0.1 second).
Occupies short space in line and with improvement factor of 50 compared to
Traditional CT power frequency electrode.
Voltage Display: 0.0~15.0KV digit, 14.2mm LED display, Accuracy +/- 1% of reading
Output Control: Front Panel Reset in Manual Mode. Closure time is selectable
0.2s/2s/5s in main board by jumper JP, Form C relay contacts (250VAC/5A) for all
Wire faults detected.
Limits the fault current without damaging the test equipment.
Short exposure time to corona does not degrade nor damage good insulation.
Distinguishes all wire faults and detects bare wire.
Safety Switch interlock.
Technical Specifications:

Specification	GW-066A   Wire High Frequency Spark Test Machine
Output Voltage	0.0~15.0KV R.M.S.
Test Voltage	1.0~15.0KV R.M.S.
Cable Diameter	0~25mm
Maximum Load Current	4mA Resistive,40mA Capacitive
Output Frequency	2.5-3.5KHznormal
Electrode lengths	Bead Chain 120mm
Fault Indication	Indicating lamp,Counting byDigital Counter
Output Control	1 Form C relayContacts(220VAC/5A)forall wire faults and bare wire faultsdetected
Input Control	SP1, SP2 input interlock control
Operating Model	Extruder ContinuousApplication
Power Source	175~264 Volts, 180VA, Single phase, 50/60 Hz
Operation Temperature	+4~45°C
Operation Humidity	<90%RH
Signal Cable Lengths	5M
Weight	Control Unit =5 kgs, Electrode = 8.5 kgs
Dimension Controller	360(L)x485(W)x90(H) mm
Gauge Head	330(L)x200(W)x390(H)
Line Speed	2000 M/min. maximum*

What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
