• Model NO.：YSDT-1000-C
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：N,a
• Internal Size(W*H*D)：1000*1000*1000mm
• Exterior Chamber Size(W*H*D)：1350*1950*1350mm
• Test Type：F1
• Concentration of Dust：Above 60000 Mg , M3
• Testing Temp.：20 Degree Celsius +,- 15 Degree Celsius
• Humidity Range：45%Rh-85%Rh
• Swirl Time：5s
• Material：Stainless Steel
• Warranty：12 Month
• Rest Time：15 Min
• Transport Package：Well Packed in Strong Wooden Cases.
• Specification：CE, ISO, SGS, TUV certified.
• Trademark：Yuanyao
• Origin：Dongguan, China(Mainland)
• HS Code：9031200000
• Production Capacity：20sets,Week

ModelYSDT-1000-FYSDT-1000-C(IEC-529)Internal Dim.W×H×D(mm)1000×1000×10001000×1000×1000External Dim.W×H×D(mm)1350×1950×13501350×1950×1350Testing TypeF1F2F3IEC60529C1C2Concentration of dust(mg/m3)Above 60000Above 3000Above 100Above 5000Above 100Testing Temp.20°C±15°CHuimidi.Range45%RH~85%RHFlow rate of dust(m/s)No Limited5m/s10m/sTesting TimeSwirl time5S or otherNORest time15min or otherTotal time5H8H8H2H6HMaterialExteriorSUS#304+Powder CoatedInteriorSUS#304Other ComponentsChamber lamp,Wiper,Casters with adjustersPower Source(K.W.)AC 1Ψ 220V 50Hz   4KW

Product detail


 In addition to Auto parts sand dust climate simulation chamber, we are also manufacturing:

Precision Oven Tester, Triple Type Temp. & Humidity Chamber, Temp. & Humidity Control Host, Air

Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test

Room, Temp. Humidity & Vibration Combined Test Chamber, Aging Oven Tester, Rain / Spray Test

Chamber, Burn-in test equipment, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester

and so on.
