• Model NO.：LS300
• Loading Method：No
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Resolution：1%
• Temperature Measurement Range：-55 Oc to + 85 Oc
• Power Supply：AC220V
• Accuracy：+,- 0.5 Oc
• Packing Size：340mm *200mm *400mm(L*W*H)
• Usage：Solar Film Vlt, IR, UV Testing
• Name：Solar Film Transmission Meter
• Item：Ls300 Solar Film Temperature Meter
• Philips Infrared Lamp：150W
• Transport Package：One Piece One Small Box
• Specification：L*W: 430mm*320mm
• Trademark：ALILULA, New Vision
• Origin：Guangzhou, China
• HS Code：9030849000
• Production Capacity：500000PCS,Month

Basic Info.

Model NO. LS300 Loading Method No Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position No Resolution 1% Temperature Measurement Range -55 Oc to + 85 Oc Power Supply AC220V Accuracy +/- 0.5 Oc Packing Size 340mm *200mm *400mm(L*W*H) Usage Solar Film Vlt, IR, UV Testing Name Solar Film Transmission Meter Item Ls300 Solar Film Temperature Meter Philips Infrared Lamp 150W Transport Package One Piece One Small Box Specification L*W: 430mm*320mm Trademark ALILULA, New Vision Origin Guangzhou, China HS Code 9030849000 Production Capacity 500000PCS/Month

Product Description

Ls300 Electricity Plastic Solar Window Tinted Film Meter Tester



LS300 Solar Film Temperature Meter is a small size, portable product for transmission value measurement. It is able to simultaneously measure and display UV, VL and IR transmission values. This meter is self-contained light sources and self-calibration. No manual adjustment is needed. The users only need power on the meter and put the testing sample in the opening. The resulting performance data appear on the display.


1.Product Specification:

Product Item	Ls300 Electricity Plastic Solar Window Tinted Film Meter Tester
Product Size	340mm *200mm *400mm(L*W*H)
Weight	about 8kg
Temperature measurement range	-55 oC to + 85 oC
Resolution	1%
Accuracy	+/- 0.5 oC
Power supply	AC220V

1. Accuracy: +/- 0.5 oC
2. Temperature measurement range: -55 oC to + 85 oC
3. Size: 340mm *200mm *400mm(L*W*H)
4. Instrument weight: about 8000 g
5. Power supply: 220V AC
6.150W Philips infrared lamp used.
7. Directly with both hands to feel the change in temperature.
8. Shows the real time temperature value and the temperature difference

2.Operation:
1).Power on: When LS300 Solar Film Temperature Meter is off, press the "ON/Hold" key.

2).Power off: Press "ON/Hold" key and hold for longer than 3 seconds, LS300 Solar Film Temperature Meter
will be powered off.

3).Auto off: No key is pressed in 3 minutes, and then LS300 Solar Film Temperature Meter will power off automatically.

4).Manual hold: If "ON/Hold" key is short pressed during measure status, transmission value will hold on the LCD, "Hold" symbol is displayed on the LCD.Press the "NO/Hold" key again will
release the "Hold" mode. When backing is off, press the "NO/Hold" key turn on the backlight.

5).Measurement: When the meter displays 100% for each value, insert the testing sample in the
" OPENING", VL, UV and IR transmission value will display simultaneously.

3.Feature:
1). UV transmission meter, IR transmission meter, Light Transmittance Meter, Three function in
ONE device.

2). Small size, portable product for transmission value measurement.

3). Simple operation, putting the testing sample in the "OPENING", UV, Visible and Infrared transmission values of the sample will simultaneously display.

4). Using for window film, solar film and other transparence material testing. Test any sample thickness up to 8mm.

4.Note:
1). When battery symbol is empty and flash, pls replace the battery.
2). Keep the " OPENING" is empty before turn on LS300 Solar Film Temperature Meter. Otherwise LS300 Solar Film Temperature Meter will display testing interface, turn off and empty the " OPENING" and turn on again.
3).+/-2% Accuracy is for Colorless and transparent material, for colorful or optical coating product
ect, it will be low accuracy.
4). When not use for a long time(e.g several months), please take the battery out.
5). Avoid contact with corrosive agents and prevent from high temperature and high humidity environment.

5.Service:
1). The meter has one-year warranty. If the meter works abnormally, please send the whole meter
to the company for maintenance.
2). Provide users with spare parts and lifelong maintenance service.
3). Provide the users with the meter inspection service for free.
4). Free technical support for long term.

6.Welcome to visit our company

GuangDong New Vision Film Co.,Ltd. is a professional manufacturer of car tint film,building film,safety film ect. Our Company is in Guangzhou,factory in Jiangmen city.We offer high
quality products to our customers from all over the world in competitive price.


7.Certification
We have passed SGS, CE, ROHS, ISO etc test, the products are deserving of your try.
