• Model NO.：KMH-150L
• Humidity Constancy：+,-2.5%R.H.
• Equipment Power：7.5kw
• Refrigeration System：Hermetic Compressor, Cascsde Refrigeration CFC
• Humidity Uniformity：+,-5.0r.H.
• Heat up Time：-40oc~+100oc Within 60mins
• Pull Down Time：+20 Oc~-40 Oc Within 80mins
• Power：AC380+,-10% 50Hz 3phase4wires+Groud Wires
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, P. R. China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Environmental Temperature and Humidity ChamberSecifications ( at +20°C  room temp.  Or+25°C  water temp with empty load)ModelKMH-S series225S408S800S1000SInterior sizelW(mm)70070010001000H(mm)70075010001000D(mm)4808008001000Exterior sizeW(mm)98098012801280H(mm)1890194021602160D(mm)1460174017501950Weight(KG)330450550650Temp. range -70 °C ~+150°C Humidity Range20 ~ 98&R.H.Temp. constancy±0.5ºC   Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.H±5.0 % R.HHeat up time -70°C  ~ +100°C , within 60 minPull down time +20°C  ~ -70°C  , within 80 minEquipment Power9.5KW10.6KW18.5KW18.5KWAmbient Temp.5ºC  ~+35ºC  Standard accessoriesSight window*1,  cable port(portΦ50mm)*1,   shelves*2,    chamber lamp*1,    power cable *2mSafety device  (standard)No fuse breaker, over pressure  over heat and over current protection for compressor,
Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Cascsde Refrigeration,                          CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesInterior materialStainless Steel Plate ( SUS 304 )Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolSystemBalanced & Humidity Control SystemWiring methodAC 380±10 %  50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available
