• Model NO.：47-T0056,C
• HS Code：90248000
• Production Capacity：100 Pieces,Month

Basic Info.

Model NO. 47-T0056/C HS Code 90248000 Production Capacity 100 Pieces/Month

Product Description

New generation Motorised sand equivalent shaker

This method for test sand equivalent provides the procedure for measuring the relative proportions of detrimental fine dust or clay-like material in soil or fine aggregates.

This Motorised sand equivalent shaker is our new generation product, using an improved graphite sliding bearing, compared to the previous generation of products, greatly reducing the operating noise, and wear resistance also increased several times. New sand equivalent shaker has built-in timer and counter at the same time, also can measure the speed during shaking. The new products also improve the mechanical structure, and can complete the vibration test of two tubes. The top of the instrument added shelving rack.



Specifications of 47-T0056/C
Rated power: 180W
Total weight: 50kg approx.
Overall dimension: 670x560x550mm
Stroke: 20.3±1cm
Rate: 180±2 strokes/min
Piston: 1kg±5g
Plastic cylinder: internal diameter 32±0.25mm, height 420mm
Washing pipe: external diameter 6±0.5mm, internal diameter 4±0.2mm
Voltage: AC 220V, 50HZ
Ambient temperature: ≤35ºC
Relative humidity: ≤85%
